PLEASE NOTE!
The sensor accuracy is defined at continuous operation (at least 3 weeks after
installation)
Self-diagnostics
The system contains complete self-diagnostic procedures. A full system test is
executed automatically every time the power is turned on. For CF8-W-Disp-CO
the
internal voltage regulators and outputs are checked. In addition, constantly during
operation, checking the valid dynamic measurement ranges checks the sensor
probes against failure. These different system checks return error bytes to the system
RAM. If any error is detected, the yellow LED will be lit until the error has vanished
and the error flag is reset. “Warm up” and “Out of Range” are the only bits that are
reset automatically after return to normal state. All other error bits have to be reset
manually after return to normal state – either by pushing MENU & ESC buttons
simultaneously for (=Entr(+-) or by power off and restart.
By pushing the push button ”MENU” the error code number Exxx is shown on the
LCD. Descriptions of the different codes are listed below.
Error code and action plan
Bit #
Error
code
Error description Suggested action
0 N/A
Fatal Error
Yellow LED continuously flashes.
Push buttons are not operating.
Try to restart sensor by power OFF/ON.
Contact local distributor
1 2 Reserved
2 4
Algorithm Error.
Indicate wrong EEPROM
configuration.
Try to restart sensor by power OFF/ON.
Check detailed settings and
configuration with UIP software version
4.3 and higher.
Contact local distributor
3 8
Output Error
Detected errors during output
signals calculation and generation.
Check connections and loads of
outputs.
Check detailed status of outputs with
UIP software version 4.3 and higher.
4 16
Self-Diagnostic Error.
May indicate the need of zero
calibration or sensor replacement.
Check detailed self-diagnostic status
with UIP software version 4.3 and
higher.
Contact local distributor
5 32
Out of Range Error
Accompanies most of other errors.
Can also indicate overload or
failures of sensors and inputs.
Resets automatically after source
of error disappearance. Try sensor in fresh air.
Check connections of temperature and
relative humidity probe.
Check detailed status of measurements
with UIP software version 4.3 and
higher.
See Note 1!
