Installation manual
CF5-W, CF5-W-Disp
Dismounting of the sensor
Pull the top part upwards
Push the front part upwards while
Fold the front part forwards and
keeping the wall plate steady
loose it from the hooks (#1)
3
2
5
1
4
1
1 top part
2 front part
3 wall plate
4 screw
5 label with
settings
inside the
top part
