Prochem Everest 408-650, LP-HP User Manual
Page 87
85
86352170 EVEREST
Heat Exchanger
REF
PART NO.
QTY
DESCRIPTION
SERIAL NO.
FROM
NOTES
1
86056840
2
SPACER, HT EXH DOOR GLIDE
2
86047890
2
GLIDE, HT EXH DOOR
3
86270770
8
NUT, 1/4-20 HEX
4
86010780
8
WASHER, 1/4 SPLIT LOCK PLTD
5
86047490
1
DOOR, EXHAUST DIRECT
6
86006670
3
SCR, 1/4-20 X 3/4 FHCS
7
86056670
1
ROD, HT EXH DOOR
8
86173940
2
ASSEMBLY, SST HEATER CORE
9
86293680
1
ASSEMBLY, COPPER HEATER CORE
10
86189720
3
PAD, BTM VAC HTR CORE
11
86273810
8
SCR, 1/4-20 X 1 HHCS SS
12A
86351740
1
HSG, VAC HE BOX, EV650
650 ONLY
12B
86353060
1
HSG, VAC HE BOX, EV408
408 ONLY
13
86177260
2
CLAMP, HOSE #10
