23
Operations
#
DTC/
Pcode
Fault Description
CAN
SPN
CAN
FMI
Turns on
MIL?
MIL Flash
Code
63 P1155 Closed-loop gasoline bank 1 A/F is too lean 520204 0 Yes 155
64 P1156 Closed-loop gasoline bank 1 A/F is too rich 520204 1 Yes 156
86 P1551 Aux Digital Input 1 High (Float Switch Voltage High) - - Yes 1551
87 P1552
AUX DIGITAL INPUT 1 low voltage-force idle-waste
tank full.
520222 3 Yes 552
88 P1553
Aux Digital Input 2 High (Float Switch Voltage High
Engine Shut Down) 1553
- - Yes 1553
89 P1554
AUX DIGITAL INPUT 2 low voltage-after 15 seconds-
engine shut-down-waste tank full
520223 4 Yes 554
94 P1612 Watchdog processor blocked outputs (RTI 1) 629 31 Yes 712
95 P1613 Microprocessor failure - RTI 2 P0629 P0031 Yes 713
96 P1614 Microprocessor failure - RTI 3 P0629 P0031 Yes 714
97 P1615 Microprocessor failure - A/D P0629 P0031 Yes 715
98 P1616 Microprocessor failure - Interrupt P0629 P0031 Yes 716
99 P1644 MIL control short to GND P1213 P0004 No 644
100 P1645 MIL control short to 12V P1213 P0003 No 645
101 P2111 Unable to reach Lower TPS P0051 P0007 Yes 211
102 P2112 Unable to reach higher TPS P0051 P0007 Yes 212
110 P2300 Ignition coil A low current P1268 P0005 Yes 411
111 P2301 Ignition coil A high current P1268 P0006 Yes 412
112 P2303 Ignition coil B low current P1269 P0005 Yes 421
113 P2304 Ignition coil B high current P1269 P0006 Yes 422
OBD = On Board diagnostics (Nomenclature)
DTC = Diagnostic Trouble Code
MIL = Malfunction Indicator Light
TPS1 = Throttle Position Sensor
EGO = Exhaust Gas Oxygen
ECT = Engine Coolant Temperature
CAM = Cam Sensor Input
CAN = Controller Ares Network
CPS = Crank Position Sensor
MAP = Manifold Absolute Pressure
Pcode= Powertrain Code
