Prochem Everest 408-650, LP-HP - Manual (Page 19)

17
Operations
Technical Specifications
Item Dimension / Capacity
Engine speed
2200 rpm (high speed)
900 rpm (idle speed)
Solution pump rpm 1357 rpm
Vacuum pump rpm 3125 rpm
Water flow rate 5 GPM (maximum)
Solution pump pressure (low pressure) 1200 PSI (maximum)
Solution pump pressure (high pressure) (Optional) 3000 PSI (maximum)
Vacuum relief valve 13" Hg
Waste tank capacity 100 gallons
Console weight (Model 408 & HP 408) 1065 lbs
Console weight (Model 650 & HP 650) 1150 lbs
Console weight (with waste tank & waste tank accessories)
(Model 408 & HP 408)
1215 lbs
Console weight (with waste tank & waste tank accessories)
(Model 650 & HP 650)
1300 lbs
Torque Values
Engine pulley 360 inch lbs 30 foot/lbs
Vacuum pump hub 300 inch/lbs 25 foot/lbs
86352170 EVEREST
