Prochem Everest 408-650, LP-HP User Manual
Page 63
61
86352170 EVEREST
Front Panel
HP Only = Used Only on High Pressure Units.
LP Only = Used Only on Low Pressure Units.
REF
PART NO.
QTY
DESCRIPTION
SERIAL NO.
FROM
NOTES
1
86133380
1
GASKET, 1/8 X 1/2 1SDA FOAM BLK
2
86012770
1
PANEL, RADIATOR CLOSEOUT
3
86014730
1
SEAL, STRT BULB SD168 X 17.5
4
86014760
1
SEAL, STRT BULB SD168 X 20.5
5
86014750
1
SEAL, STRT BULB SD168 X 19.5
6
86275210
8
SCR, 1/4-20 X 1/2 PHTR BLK DL
7
86050660
1
PANEL, GRILLE
8A
86179440
1
DECAL, FRONT HOOD 650
650 ONLY
8B
86179450
1
DECAL, FRONT HOOD HP650
650 HP ONLY
8C
86179420
1
DECAL, FRONT HOOD
408 ONLY
8D
86179430
1
DECAL, FRONT HOOD HP
408 HP ONLY
9
86178280
1
COVER, FRONT END
10
86277430
3
SCR, 1/4-20 X 3 SHCS SS
11
86279150
4
WASHER, M6 X 25 FLAT BN732 PLT
12
86273180
1
SCR, 1/4-20 X 1 HXHD GRD8
13
86179490
1
DECAL, CONDENSED OPERATING
14
86189620
1
OUTLET, EXHAUST
15
86275490
1
SCR, 1/4-20 X 1.0 BH BLK PLATE
HP ONLY
16
86279520
1
WASHER, 1/4 ID FLAT BLK
HP ONLY
17
86007820
1
SPACER, 0.50D X 0.28ID X 0.38L NYL
HP ONLY
18
86186510
1
LABEL, CAUTION HP
HP ONLY
19
86051540
1
PLT, HIGH PRESSURE LCK
HP ONLY
20
86189660
1
PAD, 1/4 TURN VIBR
HP ONLY
21A
86179470
1
DECAL, LOWER FRONT LP
LP ONLY
21B
86179480
1
DECAL, LOWER FRONT HP
HP ONLY
22A
86056140
1
PNL, LOWER FRONT, LP
LP ONLY
22B
86056130
1
PNL, LOWER FRONT, HP
HP ONLY
23
86275460
4
SCR, 1/4-20 X 3/4 BHCS BLK PLATE
24
86005680
7
NUT, 1/4-20 HEX NYLOCK
25
86010780
5
WASHER, 1/4 SPLIT LOCK PLTD
26
86274760
3
SCR, 1/4-20 X 1/2 HHCS PLTD
27
86270330
6
FLATWASHER, 1/4
28
86276410
6
SCR, 1/4-20 X 3/8 PPHMS BLK ZC NP
29
86277730
2
SCR, 1/4-20 X 2.75 BHCS BLK
30
86279400
6
WASHER, 1/4 SPLIT LOCK BLK
31
86279520
6
WASHER, 1/4 ID FLAT BLK
32
86177090
1
CLAMP, CABLE 1/2 I.D. 1/4 BLT
