Introduction
Thank you for purchasing PNI Sensor Corporation‟s CommBoard, pn 13466. The CommBoard
is a printed circuit assembly (PCA) that acts as an easy-to-use interface between a PC and certain
PNI products. The CommBoard is a UART to SPI or I
2
C bridge which receives UART
commands from the user‟s computer via a virtual communication port running over a USB line.
The applicable PNI products and their interface types are listed below.
Table 2-1: Applicable PNI Products & Interfaces
PNI Product
Interface
RM3100 Evaluation Board
I
2
C or SPI
RM3000-f Evaluation Board
SPI
V2Xe
SPI
SpacePoint Scout
I
2
C or UART
