PNI Sensor Corporation DOC#1018122 r02
PNI CommBoard User Manual Page 16
The received signal is: “00C8 00C8”. In this case, the return byte is not read.
Note the default delimiter, , is used in the received signal.
5.2.2 More RM3100 Eval Board Code Examples
Example #1: $0wn04,00,64,00,64,00,64$1
This sentence sets all three cycle count registers to 100
D
(0x64).
Example #2: $0wn00,70$1
This sentence requests a single measurement be taken on all 3 axes.
Example #3: $0wn01,71$1
This sentence places the RM3100 Eval Board in Continuous Measurement Mode.
Example #4: $0wnA4rmmm$1
This sentence first writes the address of the MSB of the MX Read register, then reads
from this byte and the subsequent 8 bytes, to provide the most recent measurement
results on all 3 axes.
5.2.3 RM3000-f Eval Board Code Examples
Example #1: $0wn83,00,64,00,64,00,64$1
This sentence sets all three cycle count registers to 100
D
(0x64).
Example #2: $0wn82 01$1
This sentence requests a single measurement be taken on all 3 axes.
Example #3: $0rc9nmmm$1
This sentence first writes the address of the MSB of the MX Read register, then reads
from this byte and the subsequent 8 bytes, to provide the most recent measurement
results on all 3 axes.
5.2.4 V2Xe Code Examples
Example #1: $0.wnaa,01,00$1.$0rnnnnnnnnnnn$1
This sentence can be used to obtain the ID packet from a V2Xe. Note the “.”
commands causes a 2 ms pause in transmission. These pauses are often necessary
when working with the V2Xe.
