KD-2300 Instruction Manual
Part III: The Equipment
••••
13
Part III: The Equipment
Operating Principle*
The system uses a principle of impedance variation which is caused by
eddy currents induced in a conductive metal target. The coupling between
a coil in a sensor and a target is dependent upon their displacement (gap).
The electronics consists of an oscillator, linearization network, amplifiers,
and a demodulator, which provides an analog voltage directly proportional
to displacement.
*Patent
Pending
Specifications
TEMPERATURE
Operating Temperature Range
Sensor**
-67
°
to 220
°
F (-55
°
C to 105
°
C)
Cable and Connector
Standard
-PVC
-67
°
to 220
°
F (-55
°
C to 105
°
C)
Electronics
32
°
to 132
°
F (0
°
C to 55
°
C)
POWER SUPPLY REQUIREMENTS:
Voltage
± 15 Vdc
Voltage Regulation
± 0.5 Vdc
Current
70mA
**Some sensors are available in Moderate Temperature versions.
Temperature range for moderate temperature sensors is
-320
°
to 400
°
F (-196
°
C to 204
°
C)
