Part II: Getting Started
••••
9
Part II: Getting Started
Basic System
Your KD-2300 system consists of these basic components:
•
Sensor(s)
•
Cable(s)
Depending upon the system, the standard sensor cable
length may be increased in increments of 5 feet (1.55 m) up to a
maximum of 30 feet (9.15 m) on special order basis.
•
Oscillator/ Demodulator
•
User manual
•
Accessory kit
Module Identification
All modules have the following identification:
a. Model number
b. Serial number
Your Series 2300 system comes configured to your specifications.
However, you will need to connect sensors and cables yourself.
Connecting the Sensors
Connect sensors to oscillator/ demodulator using the connector located
on the front of the electronics.
The model KD-2300 family consists of a sensor, a signal conditioning
electronics, and a separate interconnection cable when not integral with
the sensor. The signal conditioning electronics with each system model
has been designed to provide optimum performance with its sensor,
cable length, and target material (magnetic or non-magnetic); therefore,
1. Sensor cable length and type should not be altered.
2. Sensors are interchangeable only with others of the same type and
cable length (with slight calibration adjustment). See
CALIBRATION PROCEDURE.
3. The proper target material must be used.
