Dwyer MS2-B - Manual (Page 7)

Property
Object Identifier
Object Name
Object Type
Present Value
Status Flags
Event State
Reliability
Out Of Service
Units
Default
Value
AV6
Flow Area SqFt
ANALOG_VALUE (2)
1
0
NORMAL (0)
NO_FAULT_DETECTED(0)
FALSE (0)
Square-feet (1) Property Data
Type
BACnetObjectIdentifier
CharacterString
BACnetObjectType
Real
BACnetStatusFlags
BACnetEventState
BACnetReliability
Boolean
BACnetEngineeringUnits
Access
Read
Read
Read
Read/Write
Read
Read
Read
Read/Write
Read
Property
Object Identifier
Object Name
Object Type
Present Value
Status Flags
Event State
Reliability
Out Of Service
Units
Default
Value
AV7
Sensor Present
ANALOG_VALUE (2)
Model Specific
0
NORMAL (0)
NO_FAULT_DETECTED(0)
FALSE (0)
No units (95) Property Data
Type
BACnetObjectIdentifier
CharacterString
BACnetObjectType
Real
BACnetStatusFlags
BACnetEventState
BACnetReliability
Boolean
BACnetEngineeringUnits
Access
Read
Read
Read
Read
Read
Read
Read
Read/Write
Read
Analog Value (AV6): Setting Area in Square Feet (0.01 to 999.99).
Analog Value (AV7): Detecting if the Sensor is Working properly.
The present value of this object represents the type of pressure
sensor used in the specific model and can indicate if there is a
problem with the sensor. See Sensor Table for sensor types.
NOTICe
Present Value
0
1
2
3 Sensor
No Sensor (Error)
Hall Effect Sensor
Piezo Sensor
Capcell Sensor
Sensor Types for AV7.
Appendix IV: Analog Value Object Property Table
Property
Object Identifier
Object Name
Object Type
Present Value
Status Flags
Event State
Reliability
Out Of Service
Units
Default
Value
AV1
Velocity FPM
ANALOG_VALUE (2)
Current reading
0
NORMAL (0)
NO_FAULT_DETECTED(0)
FALSE (0)
Feet-per-minute (77) Property Data
Type
BACnetObjectIdentifier
CharacterString
BACnetObjectType
Real
BACnetStatusFlags
BACnetEventState
BACnetReliability
Boolean
BACnetEngineeringUnits
Access
Read
Read
Read
Read
Read
Read
Read
Read/Write
Read
Property
Object Identifier
Object Name
Object Type
Present Value
Status Flags
Event State
Reliability
Out Of Service
Units
Default
Value
AV2
Velocity MPS
ANALOG_VALUE (2)
Current reading
0
NORMAL (0)
NO_FAULT_DETECTED(0)
FALSE (0)
Meters-per-second (74) Property Data
Type
BACnetObjectIdentifier
CharacterString
BACnetObjectType
Real
BACnetStatusFlags
BACnetEventState
BACnetReliability
Boolean
BACnetEngineeringUnits
Access
Read
Read
Read
Read
Read
Read
Read
Read/Write
Read
Property
Object Identifier
Object Name
Object Type
Present Value
Status Flags
Event State
Reliability
Out Of Service
Units
Default
Value
AV3
Flow CFM
ANALOG_VALUE (2)
Current reading
0
NORMAL (0)
NO_FAULT_DETECTED(0)
FALSE (0)
Cubic-feet-per-minute (84) Property Data
Type
BACnetObjectIdentifier
CharacterString
BACnetObjectType
Real
BACnetStatusFlags
BACnetEventState
BACnetReliability
Boolean
BACnetEngineeringUnits
Access
Read
Read
Read
Read
Read
Read
Read
Read/Write
Read
Property
Object Identifier
Object Name
Object Type
Present Value
Status Flags
Event State
Reliability
Out Of Service
Units
Default
Value
AV4
Flow CMH
ANALOG_VALUE (2)
Current reading
0
NORMAL (0)
NO_FAULT_DETECTED(0)
FALSE (0)
Cubic-meters-per-hour (135) Property Data
Type
BACnetObjectIdentifier
CharacterString
BACnetObjectType
Real
BACnetStatusFlags
BACnetEventState
BACnetReliability
Boolean
BACnetEngineeringUnits
Access
Read
Read
Read
Read
Read
Read
Read
Read/Write
Read
Property
Object Identifier
Object Name
Object Type
Present Value
Status Flags
Event State
Reliability
Out Of Service
Units
Default
Value
AV5
Velocity K Value
ANALOG_VALUE (2)
1
0
NORMAL (0)
NO_FAULT_DETECTED(0)
FALSE (0)
No units (95) Property Data
Type
BACnetObjectIdentifier
CharacterString
BACnetObjectType
Real
BACnetStatusFlags
BACnetEventState
BACnetReliability
Boolean
BACnetEngineeringUnits
Access
Read
Read
Read
Read/Write
Read
Read
Read
Read/Write
Read
Analog Value (AV1): Velocity in Feet per Minute.
Analog Value (AV2): Velocity in Meters per Second.
Analog Value (AV3): Volumetric Flow in Cubic Feet per Minute.
Analog Value (AV4): Volumetric Flow in Cubic Meters per Hour.
Analog Value (AV5): Setting K Factor Range (0 to 9.999).
