Appendix III: Analog Input Object Property Table
Property
Object Identifier
Object Name
Object Type
Present Value
Status Flags
Event State
Reliability
Out Of Service
Units
Default
Value
AI1
Pressure inWC
ANALOG_INPUT (0)
Current reading
0
NORMAL (0)
NO_FAULT_DETECTED(0)
FALSE (0)
Inches-of-water (58) Property Data
Type
BACnetObjectIdentifier
CharacterString
BACnetObjectType
Real
BACnetStatusFlags
BACnetEventState
BACnetReliability
Boolean
BACnetEngineeringUnits
Access
Read
Read
Read
Read
Read
Read
Read
Read/Write
Read
Property
Object Identifier
Object Name
Object Type
Present Value
Status Flags
Event State
Reliability
Out Of Service
Units
Default
Value
AI2
Pressure Pascals
ANALOG_INPUT (0)
Current reading
0
NORMAL (0)
NO_FAULT_DETECTED(0)
FALSE (0)
pascals (53) Property Data
Type
BACnetObjectIdentifier
CharacterString
BACnetObjectType
Real
BACnetStatusFlags
BACnetEventState
BACnetReliability
Boolean
BACnetEngineeringUnits
Access
Read
Read
Read
Read
Read
Read
Read
Read/Write
Read
Property
Object Identifier
Object Name
Object Type
Present Value
Status Flags
Event State
Reliability
Out Of Service
Units
Default
Value
AI3
Pressure Kilo-Pascals
ANALOG_INPUT (0)
Current reading
0
NORMAL (0)
NO_FAULT_DETECTED(0)
FALSE (0)
kilopascals (54) Property Data
Type
BACnetObjectIdentifier
CharacterString
BACnetObjectType
Real
BACnetStatusFlags
BACnetEventState
BACnetReliability
Boolean
BACnetEngineeringUnits
Access
Read
Read
Read
Read
Read
Read
Read
Read/Write
Read
Property
Object Identifier
Object Name
Object Type
Present Value
Status Flags
Event State
Reliability
Out Of Service
Units
Default
Value
AI4
Pressure mmWC
ANALOG_INPUT (0)
Current reading
0
NORMAL (0)
NO_FAULT_DETECTED(0)
FALSE (0)
Millimeters-of-water (206) Property Data
Type
BACnetObjectIdentifier
CharacterString
BACnetObjectType
Real
BACnetStatusFlags
BACnetEventState
BACnetReliability
Boolean
BACnetEngineeringUnits
Access
Read
Read
Read
Read
Read
Read
Read
Read/Write
Read
Analog Input (AI1): Pressure in inches of water column.
Analog Input (AI2): Pressure in Pascals.
Analog Input (AI3): Pressure in Kilo-Pascals.
Analog Input (AI4): Pressure in millimeters of water column.
