Dwyer 43000 - Manual (Page 5)

Model
43000-0
43001
43002
43003
43004
43005
43006
43008
43010
43015
43020
43025
43030
43040
43050.
43060
43080
43100
43150
43200
43300
43400
43500
Range,
Inches
of Water
0 to 0.5
0 to 1.0
0 to 2.0
0 to 3.0
0 to 4.0
0 to 5.0
0 to 6.0
0 to 8.0
0 to 10
0 to 15
0 to 20
0 to 25
0 to 30
0 to 40
0 to 50
0 to 60
0 to 80
0 to 100
0 to 150
0 to 200
0 to 300
0 to 400
0 to 500
Minor
Div.
.01
.02
.05
.10
.10
.10
.20
.20
.20
.50
.50
.50
1.0
1.0
1.0
2.0
2.0
2.0
5.0
5.0
10.0
10.0
10.0
Model
43302
43304
43310
43320
43330
Range,
Zero Center
Inches of Water
1 to 0 to 1
2 to 0 to 2
5 to 0 to 5
10 to 0 to 10
15 to 0 to 15
Minor
Div.
.05
.10
.20
.50
1.0
Model
43201
43202
43203
43204
43205
43210
43215
43220
43230S
43240S
43260S
43280S
432100S
432200S
432300S
436004S
436006S
436010S
436020S
463040S
436060S
Range
PSIG
0 to 1
0 to 2
0 to 3
0 to 4
0 to 5
0 to 10
0 to 15
0 to 20
0 to 30
0 to 40
0 to 60
0 to 80
0 to 100
0 to 200
0 to 300
0 to 400
0 to 600
0 to 1000
0 to 2000
0 to 4000
0 to 6000
Minor
Div.
PSIG
.02
.05
.10
.10
.10
.20
.50
.50
1.0
1.0
2.0
2.0
2.0
5.0
10
10
20
20
50
100
200
Model
43000-20 MM
43000-25 MM
43000-50 MM
43000-80 MM
43000-100 MM
Range,
MM of water
0 to 20
0 to 25
0 to 50
0 to 80
0 to 100
Minor
Div.
(MM)
.50
.50
1.0
2.0
2.0
Model
43000-15 CM
43000-20 CM
43000-25 CM
43000-40 CM
43000-50 CM
43000-80 CM
43000-100 CM
43000-150 CM
43000-200 CM
43000-250 CM
43000-300 CM
Range,
CM of water
0 to 15
0 to 20
0 to 25
0 to 40
0 to 50
0 to 80
0 to 100
0 to 150
0 to 200
0 to 250
0 to 300
Minor
Div.
(MM)
.50
.50
.50
1.0
1.0
2.0
2.0
5.0
5.0
5.0
10.0
Model
43300-4 CM
43300-10 CM
43300-30 CM
Range,
Zero Center
CM of water
2 to 0 to 2
5 to 0 to 5
15 to 0 to 15 Minor
Div.
(CM)
.10
.20
1.0
Model
43000-125 Pa
43000-250 Pa
43000-500 Pa
43000-750 Pa
Range,
Pascals
0 to 125
0 to 250
0 to 500
0 to 750
Minor
Div.
(Pascals)
5.0
5.0
10.0
25.0
Model
43300-500 Pa
Range,
Zero Center
Pascals
250 to 0 to 250 Minor
Div.
(Pascals)
10.0
Model
43000-1 kPa
43000-1.5 kPa
43000-2 kPa
43000-3 kPa
43000-4 kPa
43000-5 kPa
43000-8 kPa
43000-10 kPa
43000-15 kPa
43000-20 kPa
43000-25 kPa
43000-30 kPa
Range,
Kilopascals
0 to 1
0 to 1.5
0 to 2
0 to 3
0 to 4
0 to 5
0 to 8
0 to 10
0 to 15
0 to 20
0 to 25
0 to 30
Minor
Div.
(Kilopascals)
.02
.05
.05
.10
.10
.10
.20
.20
.50
.50
.50
1.0
Model
43300-1 kPa
43300-3 kPa
Range,
Zero Center
Kilopascals
.5 to 0 to .5
1.5 to 0 to 1.5 Minor
Div.
(Pascals)
.02
.10
Models and Ranges
Note: The Capsu-Photohelic ® pressure switch/gage may be used in an Underwriters Laboratories approved industrial control panel if the usage
conforms to U/L specifications for the acceptance of unlisted components.
