Overview  1
ConfigM30 User's Manual
Overview
—
INTRODUCTION
ConfigM30 provides an easy way to customize your gauge. Using a special serial cable (P/N: 1928) for Revision A, B, or C calibrators; a standard USB to micro
USB cable for Revision D calibrators; and a computer running Windows and ConfigM30 you can:
•
View and print an as receive versus as left change report
•
Load and save custom configurations
•
Return the gauge to factory configuration
•
Select pressure units (e.g., remove inches Hg if you never use this scale)
•
Create special pressure units with custom icons
•
Adjust (calibrate) the gauge
•
Identify firmware version
•
Password protect the gauge to prevent unauthorized changes
•
Select your preferred H 2 O water density: 4 °C, 60 °F, 68 °F/20 °C
•
Store a message or identification number
Features not available on your gauge will be grayed out in ConfigM30.
!
CAUTION: Changing the settings of your gauge using this program can cause the unit to display inaccurate readings or behave differently than the
factory defaults. Only personnel qualified to make changes should do so.
Communication Port: Revision Identification
30 Series Serial port 30 Series Micro-USB port
Revision A, B, or C units Revision D or later units
