PROGRAMMING
MPORTANT I
You must connect terminals 1 and 5 together to enable the programming mode. After all programming is complete, remove the
connection between terminals 1 and 5 to prevent the unit from being reprogrammed by mistake.
To access the programming screens, press repeatedly until the Program Mode (1 through 7) you want displays on
the screen .
1 . Once you select a program, press
R to either cause the left digit of that value to flash (scale factors modes 1, 4 & 6), or
to change the parameters for the other programming modes (Decimal Point Position and Totalizer Reset) .
2 . On program modes 1, 4 & 6, use R and in combination to choose individual digits and change their value .
OTEE: N On program modes 1, 4 & 6, you can advance to the next program mode only if a digit is not flashing . Press R
until the display stops flashing .
R
1.01.000
Mode 1E: Totalizer Scaler multiplies the input pulses by this number (programmable from 0 .0001
to 99 .9999) and displays the results as the totalizer value .
R
2. oFF
Mode 2E: Totalizer Decimal Point sets the decimal point on the totalizer display from no decimal
(OFF) to 0 .00000 .
R
3. 1.000
Mode 3E: Rate Scale Factor Decimal Point sets the decimal in Rate Scale Factor number, from no
decimal to 0 .000 .
R
4. 9999
Mode 4E: Rate Scale Factor multiplies the input pulses by this number, which can be programmed
in conjunction with the Rate Decimal Point for a number from 0 .001 to 9999 .
R
5. oFF
Mode 5E: Rate Decimal Point sets the decimal point on the Rate of Flow display from no decimal
(off) to 0 .0000 . You can program the display to have a dead zero (----0), for a 5-digit display with the
least significant digit always being 0 .
R
6.0.9999
Mode 6E: Pulse Output Scale Factor multiplies the input pulses by a number from 0 .0001 to 0 .9999
and sends them to output terminals 6 & 7 .
R
7. on
Mode 7E: Front Panel Reset Enable When set to ON, press R to reset the totalizer to zero . When
set to OFF, the totalizer can only be reset through the remote reset input
(see “Wiring Instructions” on page 7 ) .
R
8. on
Mode 8E: Pulse Output Enable When set to ON, the solid-state relay output will pulse to
re-transmit input pulses . If set to OFF, it will not activate . Use the OFF setting to conserve battery
life if not using the output .
