SPECIFICATIONS
Wetted Materials
Sensor Housing and Enhancing Jet (If Applicable)
PVC - Virgin polyvinyl chloride, type 1, grade 1
PVDF - Virgin polyvinylidene fluoride
Sensor Nom. Pipe Pipe GPM GPM Hz Hz
# Mat'l Pipe OD ID K Offset min max min max
400200 PVC 1/2 #80 .0840 in 0.546 0.413 0.3496 0.75 15.00 1.46 35.97
401200 PVC 3/4 #80 1.050 in 0.824 0.5735 0.2638 1.75 35.00 2.78 60.76
402000 PVC 1 #80 1.315 in 0.957 0.6134 0.1826 2.25 45.00 3.48 73.17
410200 PVC 1/2 #80 .0840 in 0.546 0.1421 0.8474 0.18 6.00 0.48 41.37
411200 PVC 3/4 #80 1.050 in 0.824 0.3287 0.2159 0.40 13.00 1.00 39.33
400300 PVDF 1/2" 20mm 16.2mm 0.5987 0.0008 1.00 20.00 1.66 33.40
400400 (0.787in)
(0.638in)
400500
401300 PVDF 3/4" 25mm 21.2mm 0.613 0.02664 1.75 35.00 2.82 57.06
401400 (0.984in)
(0.835in)
401500
402300 PVDF 1"
32mm 27.2mm 0.6266 0.0314 3.00 50.00 4.75 79.76
402400 (1.260in) (1.071in)
402500
410300 PVDF 1/2" 20mm 16.2mm 0.1445 0.4841 0.25 8.00 1.24 54.87
410400 (0.787in)
(0.638in)
410500
411300 PVDF 3/4" 25mm 21.2mm 0.3195 0.4679 0.40 14.00 0.78 44.28
411400 (0.984in)
(0.835in)
411500
Figure 7: Calibration Table
Analog versions of the Series 4000 are precalibrated at the factory using the flow ranges below.
Sensor Nom. Pipe Pipe 4mA 20mA
# Mat'l Pipe OD ID Flow Flow
400210 PVC 1/2 #80 .0840 in 0.546 0 20
401210 PVC 3/4 #80 1.050 in 0.824 0 30
402010 PVC 1 #80 1.315 in 0.957 0 40
410210 PVC 1/2 #80 .0840 in 0.546 0 8
411210 PVC 3/4 #80 1.050 in 0.824 0 12
400310 PVDF 1/2" 20mm 16.2mm
400410 (0.787in) (0.638in) 0 20
400510
401310 PVDF
3/4" 25mm 21.2mm
401410 (0.984in) (0.835in) 0 30
401510
402310 PVDF
1" 32mm 27.2mm
402410 (1.260in) (1.071in) 0 40
402510
410310 PVDF
1/2" 20mm 16.2mm
410410 (0.787in) (0.638in) 0 8
410510
411310 PVDF
3/4" 25mm 21.2mm
411410 (0.984in) (0.835in) 0 12
411510
Figure 8: Calibration Table - Analog
