Density Effect (Specific Gravity)
Any fluid density change from stated standards has a proportional effect on meter accuracy . Special scales can be supplied if
actual specific gravity decreases accuracy beyond application limits . Corrections for more or less dense fluids can be made to
standard scales using the following correction factors:
1 0 .
Specific Gravity
for water/water-based meters
0 876 .
Specific Gravity
for petroleum-based meters
7000
6000
5000
4000
3000
2000
1000
0
MAXIMUM OPERA
TING PRESSURE, PSI
TEMPERATURE, DEGREES F
TEMPERATURE DERATING CURVES
CONTINUOUS TEMPERATURE
INTERMITTENT TEMPERATURE
Aluminum
Brass
Stainless Steel
Stainless Steel
0 100 200 300 400 500
Figure 8: Pressure vs temperature
