Section II

Parts Breakdown

PART NUMBER

FIGURE

AND

INDEX NO.

DESCRIPTION

FLOWMETER

SHELL

3/4 –inch valve

1-1/4-inch valve

2-inch valve

16-1

-2
-3
-4
-5
-6

WORCESTER VALVE*
ROLL PIN
COUPLING
PIN
BRACKET
HANDLE ASSEMBLY
WITHOUT LIGHT SHELL
WITHOUT LIGHT SHELL
WITHOUT LIGHT SHELL
WITH LIGHT SHELL
WITH LIGHT SHELL
WITH LIGHT SHELL

1
2

3 thru 7

1
2

3 thru 7

411TB-3/4
3/16”x1-1/8”
48467-3/4
703563
48458

3-82900C-9
4-82900C-9
6-82900C-9
7-82900C-9
8-82900C-9

10-82900C-9

411TB-1-1/4
3/16”x1-1/8”
48467-1-1/4
703563
48458

3-82900C-9
4-82900C-9
6-82900C-9
7-82900C-9
8-82900C-9

10-82900C-9

411TB-2
3/16”x1-1/8”
48468-2
703563
48458

--
--
5-82900C-9
--
--
9-82900C-9

* Teflon Seal Kits available. When ordering, specify valve size.
