Badger Meter Hydrometer User Manual
Page 15

Section II
Parts Breakdown
SECTION II
PARTS BREAKDOWN
FIGURE
AND
INDEX NO.
PART
NUMBER
DESCRIPTION
QTY
PER
ASSY
13-
-1
-2
-3
-4
-5
25861
25862
85309
AN6230-8
25867A
5 / 16-24 x 1
BURST DISC ASSEMBLY
STRAINER ASSY
BLOWOUT DISC
“O” RING
THREADED END FLANGE
SOCKET HEAD SCREW
1
1
1
1
1
4
14-
-1
-2
36638
36634
No Number
No Number
AN6230-4
AN6230-13
INLET ELBOW ASSY, 2-inch
INLET ELBOW ASSY, 3-inch
INLET ELBOW, 2-inch
INLET ELBOW, 3-inch
“O” RING, 2-inch elbow
“O” RING, 3-inch elbow
1
1
1
1
1
1
13
