Recordall®, 308 Summator/Splitter
Summator/Splitter with 308 Connectors
RTR
6’ Low Flow Cable
6’ High Flow Cable
Double Register Input
Summator/Splitter
9” Cable with 308 Connector
for ORION/GALAXY or 308
Connector Harness
RTR
6’ Input Cable
Single Register Input
Summator/Splitter
9” Cable with 308 Connector for
ORION/GALAXY or 308 Connector Harness
9” Cable with 308 Connector for
ORION/GALAXY or 308 Connector Harness
Summator/Splitter with Itron In-line Connectors
6’ Low Flow Cable
6’ High Flow Cable
Double Register Output
Summator/Splitter
25’ Cable with ITRON Connector
9” Cable with 308 Connector for
ORION/GALAXY or 308 Connector Harness
RTR
RTR
6’ Input Cable
Single Register Output
Summator/Splitter
25’ Cable with ITRON Connector
9” Cable with 308 Connector for
ORION/GALAXY or 308 Connector Harness
