FEATURES
HED
High Efficiency
HEDQ
High Efficiency - Quiet
HE+D
High Efficiency Plus
HE+DQ
High Efficiency Plus - Quiet
● Standard
○ Optional Extra
- Not available
Construction
Acoustically lined compressor enclosure
-
●
-
●
Standard Height Condenser Fan Discharge Plenum (300mm)
Extended Condenser Fan Discharge Plenum (800mmm)
Evaporator / Waterside
Shell & Tube evaporator with immersion heater & thermostat
●
●
●
●
Grooved water connections and counter pipe assembly
●
●
●
●
Flow switch
Waterside Differential Pressure Switch
Pumps - Fixed Speed
Low Energy Pumps - Variable Speed incorporating Electronic Flow Metering System
Condenser
Condenser Coils - Enhanced
Standard Size
Larger Size
Standard Size
Larger Size
Corrosion Resistant Condenser Coils
Coil Guards
Head Pressure Control - Voltage Regulated
●
-
-
-
Head Pressure Control - Electronically Commutated (EC) Regulated
●
●
●
Low speed Axial condenser fan with Sickle blades
●
-
●
-
Extra Low speed Axial condenser fan with Sickle blades
-
●
-
●
Refrigeration
Twin screw compressors with low current Star/Delta Start
●
●
●
●
Dual independent refrigeration circuits
●
●
●
●
Electronic Expansion Valve (EEV)
●
●
●
●
Economiser with dedicated EEV
●
●
●
●
Maintainable Dual Pressure relief valve assembly
●
●
●
●
Discharge line mufflers and noise traps
-
●
-
●
Liquid line sight glass
●
●
●
●
Liquid and Discharge line ball valves
●
●
●
●
Large capacity filter drier with replaceable cores
●
●
●
●
Manual reset HP/LP Switch (LP via microprocessor)
●
●
●
●
Suction and liquid pressure transducers
●
●
●
●
Anti Vibration Mounts
Leak Detection System
-
-
Electrical
Emergency stop
●
●
●
●
Individual door isolated mains power compartments for each refrigeration CCT, fans & pump option
●
●
●
●
Dedicated bus-bar chamber for incoming 3-phase & earth mains power supply
●
●
●
●
Closed transition Star/Delta Start
Connections for External Trace Heating
●
●
●
●
Power Factor Correction
●
Controls
Microprocessor Controller
●
●
●
●
Energy Manager
Electronic compressor protection module with phase & rotation protection
●
●
●
●
Phase Rotation Protection
●
●
●
●
Sequence Control - Chiller Sequence Manager
Remote Setpoint Adjust 0-10 V Signal
BMS interface Card
