Air On Coil
Water
In/Out °C
Output kW
Input kW
Output kW
Input kW
Output kW
Input kW
Output kW
Input kW
Output kW
Input kW
Output kW
Input kW
OPC800HE+
OPC850HE+
OPC900HE+
OPC950HE+
OPC1000HE+
OPC1100HE+
D
25°C
10 / 5
861.7
224.1
905.9
237.7
963.3
253.1
1021.0
270.8
1066.9
281.6
1112.8
292.3
11 / 6
886.6
225.9
931.6
239.6
991.1
255.5
1050.9
273.8
1098.0
284.2
1145.1
294.7
12 / 7
911.9
227.6
957.6
241.5
1019.3
257.9
1081.2
276.8
1129.5
286.9
1177.9
297.1
13 / 8
937.6
229.4
984.1
243.4
1048.0
260.3
1112.1
279.8
1161.6
289.7
1211.1
299.6
14 / 9
963.6
231.2
1010.9
245.2
1077.1
262.7
1143.4
282.9
1194.1
292.5
1244.8
302.1
15 / 10
989.9
233.1
1038.0
247.1
1106.6
265.1
1175.2
286.0
1227.1
295.3
1278.9
304.6
30°C
10 / 5
829.8
249.3
872.6
267.0
926.5
280.6
980.7
296.5
1025.5
308.5
1070.3
320.6
11 / 6
854.0
251.2
897.6
268.9
953.6
283.1
1009.8
299.5
1055.5
311.4
1101.3
323.3
12 / 7
878.6
253.2
923.0
270.9
981.0
285.5
1039.3
302.5
1086.1
314.3
1132.8
326.0
13 / 8
903.5
255.1
948.7
272.8
1008.9
288.0
1069.3
305.6
1117.0
317.2
1164.8
328.8
14 / 9
928.7
257.0
974.8
274.8
1037.2
290.4
1099.7
308.7
1148.4
320.2
1197.1
331.7
15 / 10
954.3
258.9
1001.2
276.7
1066.0
292.9
1130.6
311.8
1180.3
323.2
1230.0
334.5
35°C
10 / 5
794.1
278.9
835.9
300.3
885.8
313.1
936.0
327.9
979.5
342.6
1023.1
357.2
11 / 6
817.5
281.0
860.1
302.4
912.0
315.7
964.2
331.1
1008.5
345.6
1052.8
360.2
12 / 7
841.2
283.1
884.7
304.5
938.7
318.3
992.8
334.2
1037.9
348.7
1082.9
363.2
13 / 8
865.3
285.1
909.6
306.5
965.7
320.8
1021.9
337.4
1067.7
351.8
1113.5
366.3
14 / 9
889.6
287.2
934.8
308.6
993.2
323.4
1051.3
340.6
1097.9
355.0
1144.6
369.4
15 / 10
914.3
289.2
960.4
310.6
1021.0
325.9
1081.2
343.8
1128.6
358.2
1176.0
372.6
40°C
10 / 5
754.6
312.9
796.1
337.4
841.3
350.5
886.8
365.3
929.0
383.6
971.2
401.9
11 / 6
777.1
315.1
819.4
339.7
866.6
353.3
914.1
368.6
956.9
386.9
999.6
405.1
12 / 7
800.0
317.2
843.1
341.9
892.4
356.0
941.8
371.9
985.1
390.1
1028.5
408.4
13 / 8
823.1
319.4
867.1
344.1
918.5
358.7
969.9
375.2
1013.8
393.4
1057.7
411.6
14 / 9
846.6
321.5
891.4
346.3
945.0
361.4
998.5
378.5
1042.9
396.7
1087.4
415.0
15 / 10
870.3
323.7
916.1
348.4
971.9
364.0
1027.4
381.7
1072.5
400.0
1117.5
418.3
DQ
25°C
10 / 5
851.0
230.0
904.1
239.5
958.3
256.1
1004.4
277.0
1049.3
288.6
1094.1
300.2
11 / 6
875.5
231.9
929.7
241.4
985.9
258.6
1033.6
280.2
1079.5
291.6
1125.5
302.9
12 / 7
900.4
233.9
955.7
243.3
1013.9
261.1
1063.3
283.4
1110.3
294.6
1157.3
305.7
13 / 8
925.6
235.8
982.1
245.1
1042.3
263.6
1093.4
286.7
1141.5
297.6
1189.5
308.6
14 / 9
951.1
237.8
1008.9
247.0
1071.1
266.1
1124.0
290.0
1173.1
300.7
1222.2
311.5
15 / 10
977.0
239.8
1036.0
248.9
1100.3
268.6
1155.0
293.3
1205.1
303.9
1255.3
314.5
30°C
10 / 5
817.6
256.9
870.2
269.2
920.7
284.6
962.2
305.2
1005.8
318.7
1049.4
332.3
11 / 6
841.3
259.0
895.2
271.2
947.5
287.1
990.5
308.5
1035.0
321.9
1079.5
335.4
12 / 7
865.4
261.1
920.5
273.2
974.7
289.7
1019.3
311.8
1064.6
325.2
1110.0
338.5
13 / 8
889.8
263.2
946.2
275.1
1002.3
292.3
1048.5
315.2
1094.7
328.5
1140.9
341.8
14 / 9
914.5
265.4
972.2
277.1
1030.3
294.9
1078.1
318.6
1125.2
331.8
1172.2
345.0
15 / 10
939.6
267.5
998.6
279.0
1058.7
297.4
1108.2
321.9
1156.0
335.2
1203.9
348.4
35°C
10 / 5
780.3
288.2
833.0
303.1
879.1
318.0
915.6
339.2
957.9
355.9
1000.1
372.6
11 / 6
803.2
290.5
857.1
305.3
905.1
320.8
943.0
342.6
985.9
359.3
1028.8
376.0
12 / 7
826.4
292.8
881.6
307.4
931.4
323.5
970.9
346.1
1014.4
362.8
1057.9
379.5
13 / 8
849.9
295.0
906.4
309.5
958.2
326.2
999.1
349.7
1043.3
366.3
1087.4
383.0
14 / 9
873.7
297.3
931.6
311.5
985.3
328.9
1027.8
353.2
1072.6
369.9
1117.3
386.6
15 / 10
897.8
299.6
957.1
313.6
1012.8
331.6
1056.8
356.7
1102.2
373.5
1147.6
390.3
40°C
10 / 5
739.5
323.7
792.5
341.0
833.7
356.4
864.9
378.7
905.7
399.7
946.5
420.7
11 / 6
761.4
326.1
815.7
343.3
858.8
359.3
891.4
382.4
932.6
403.4
973.9
424.3
12 / 7
783.7
328.5
839.3
345.6
884.2
362.2
918.3
386.1
960.0
407.1
1001.6
428.1
13 / 8
806.2
330.9
863.2
347.8
910.0
365.1
945.6
389.8
987.7
410.8
1029.8
431.8
14 / 9
829.1
333.3
887.4
350.0
936.2
367.9
973.3
393.4
1015.8
414.5
1058.4
435.6
15 / 10
852.2
335.7
911.9
352.2
962.7
370.7
1001.4
397.1
1044.3
418.3
1087.3
439.5
1
Output kW
=
cooling duty.
Unit water flow rate (l/s)
=
at 100% water. For glycol use, refer to
7
Output kW
4.19 x
T
2
Input kW
=
compressor + fan input power.
3
Data applicable for chilled water
ΔT at 5°C
4
Evaporator fouling factor = 0.44 x 10
-4
m² K/W.
5
Interpolate for water temperatures between those quoted, do not extrapolate.
6
For conditions outside those quoted, please refer to Airedale.
