Airedale OptiChill FreeCool 500kW - 1365kW - Manual (Page 43)

Chillers OPTICHILL
™
Chillers
43
Technical Manual : 6530166 V1.6.0 02_2013
OPC700HEDQ14 OPC750HEDQ14 OPC800HEDQ14 OPC850HEDQ14 OPC900HEDQ16 OPC950HEDQ16 OPC1000HEDQ18 OPC1100HEDQ18
709.2 754.8 810.4 852.1 904.6 940.0 999.3 1041.8
246.9 276.7 303.5 328.6 339.9 364.0 372.1 390.3
2.87 2.73 2.67 2.59 2.66 2.58 2.69 2.67
3.75 3.66 3.69 3.70 3.61 3.45 3.57 3.60
0, 20, 40, 50, 60, 70, 80, 90, 100
2600 x 2200 x
8100
2600 x 2200 x
8100
2600 x 2200 x
8100
2600 x 2200 x
8100
2600 x 2200 x
9100
2600 x 2200 x
9100
2600 x 2200 x
10100
2600 x 2200 x
10100
8030 8500 8680 8690 9260 9350 9860 9880
8420 8910 9210 9220 9780 9860 10390 10420
Base: Plain Galvanised Steel
Panels: Galvanised Sheet Steel, Epoxy Baked Powder Paint, Light Grey (RAL 7035)
Shell & Tube
Class O / UV Stable
383.7 383.7 504.4 504.4 504.4 504.4 504.4 504.4
55.2 55.2 73.6 73.6 73.6 73.6 73.6 73.6
Copper Tube / Aluminium Fins
36.1 36.1 36.1 36.1 41.3 41.3 46.4 46.4
61.6 61.6 61.6 61.6 70.4 70.4 79.2 79.2
Axial - Sickle Bladed Fan
14 14 14 14 16 16 18 18
800 800 800 800 800 800 800 800
750 750 750 750 750 750 750 750
Microprocessor Controlled EC (Electronically Commutated) Fans
Screw - Twin
1 + 1 1 + 1 1 + 1 1 + 1 1 + 1 1 + 1 1 + 1 1 + 1
35 + 19 35 + 35 35 + 35 35 + 35 35 + 35 35 + 35 35 + 35 35 + 35
Ester Oil
Dual Circuit
Electronic Expansion Valve (EEV)
R134a
145 + 145 145 + 145 155 + 155 155 + 155 180 + 170 180 + 180 195 + 195 195 + 195
Grooved type Coupling & Pipe Assembly
DN200 PN16 DN200 PN16 DN200 PN16 DN200 PN16 DN200 PN16 DN200 PN16 DN200 PN16 DN200 PN16
1/2 1/2 1/2 1/2 1/2 1/2 1/2 1/2
2437 2594 2785 2928 3109 3231 3434 3581
10 10 10 10 10 10 10 10
In Line Pump - Fixed Speed Motor
82 78 92 89 85 83 78 100
174 169 183 180 177 174 169 166
In Line Pump - Variable Speed Motor
82 77 91 88 112 109 105 101
169 164 178 175 172 169 228 224
2600 x 2570 x
8100
2600 x 2570 x
8100
2600 x 2570 x
8100
2600 x 2570 x
8100
2600 x 2570 x
9100
2600 x 2570 x
9100
2600 x 2570 x
10100
2600 x 2570 x
10100
