Sound Data
GLOBAL CHILLER SOUND LEVEL VALUES - HIGH EFFICIENCY
Standard D Models
Sound
Measurement Overall
dB(A)
Frequency (Hz) dB
63 125 250 500 1000 2000 4000
OPC500HED8
Power 100 76 89 92 102 93 85 74
Pressure @ 10m 68 44 57 60 70 61 53 42
OPC525HED8
Power 98 76 89 91 100 92 85 74
Pressure @ 10m 66 44 57 59 68 60 53 42
OPC550HED8
Power 95 76 89 89 95 91 85 73
Pressure @ 10m 63 44 57 57 63 59 53 41
OPC600HED10
Power 97 76 90 91 96 92 87 74
Pressure @ 10m 65 44 58 59 64 60 55 42
OPC650HED10
Power 98 76 90 92 97 93 88 74
Pressure @ 10m 66 44 58 60 65 61 56 42
OPC700HED12
Power 97 77 92 95 97 93 87 77
Pressure @ 10m 64 44 59 62 64 60 54 44
OPC750HED12
Power 97 77 93 97 96 93 85 79
Pressure @ 10m 64 44 60 64 63 60 52 46
OPC800HED12
Power 97 77 92 98 96 91 85 78
Pressure @ 10m 64 44 59 65 63 58 52 45
OPC850HED12
Power 96 77 91 99 96 90 84 77
Pressure @ 10m 63 44 58 66 63 57 51 44
OPC900HED14
Power 98 77 92 101 98 91 86 76
Pressure @ 10m 65 44 59 68 65 58 53 43
OPC950HED14
Power 99 78 92 102 100 91 87 75
Pressure @ 10m 66 45 59 69 67 58 54 42
OPC1000HED16
Power 99 78 93 102 99 93 87 77
Pressure @ 10m 66 45 60 69 66 60 54 44
OPC1100HED16
Power 99 78 93 101 98 94 87 78
Pressure @ 10m 66 45 60 68 65 61 54 45
Quiet DQ Models
Sound
Measurement Overall
dB(A)
Frequency (Hz) dB
63 125 250 500 1000 2000 4000
OPC500HEDQ10
Power 94 82 80 89 94 89 81 69
Pressure @ 10m 62 50 48 57 62 57 49 37
OPC525HEDQ10
Power 92 82 80 87 92 88 80 69
Pressure @ 10m 60 50 48 55 60 56 48 37
OPC550HEDQ10
Power 90 82 80 84 88 87 80 68
Pressure @ 10m 58 50 48 52 56 55 48 36
OPC600HEDQ10
Power 91 82 80 87 89 88 82 68
Pressure @ 10m 59 50 48 55 57 56 50 36
OPC650HEDQ10
Power 92 82 80 88 90 89 84 69
Pressure @ 10m 60 50 48 56 58 57 52 37
OPC700HEDQ14
Power 92 83 86 92 89 89 83 73
Pressure @ 10m 59 50 53 59 56 56 50 40
OPC750HEDQ14
Power 92 83 88 94 89 89 80 75
Pressure @ 10m 59 50 55 61 56 56 47 42
OPC800HEDQ14
Power 92 83 86 96 89 87 80 74
Pressure @ 10m 59 50 53 63 56 54 47 41
OPC850HEDQ14
Power 91 83 84 96 88 84 80 72
Pressure @ 10m 58 50 51 63 55 51 47 39
OPC900HEDQ16
Power 93 84 85 99 91 86 82 71
Pressure @ 10m 60 51 52 66 58 53 49 38
OPC950HEDQ16
Power 94 84 85 100 92 87 83 68
Pressure @ 10m 61 51 52 67 59 54 50 35
OPC1000HEDQ18
Power 94 84 85 99 91 89 83 72
Pressure @ 10m 61 51 52 66 58 56 50 39
OPC1100HEDQ18
Power 94 84 86 99 91 90 83 73
Pressure @ 10m 61 51 53 66 58 57 50 40
1 dB(A) is the overall sound level, measured on the A scale.
2 All sound data measured at nominal conditions: Water in/out 12/7°C at 35°C ambient.
3 Based on standard unit, for units fitted with optional extras, please contact Airedale.
The Sound Pressure data quoted is only valid in free field conditions, where the unit is installed on a reflective base. If the equipment is
placed adjacent to a reflective wall, values may vary to those stated, typically increasing by 3dB for each side added.
