Sound Data
GLOBAL CHILLER SOUND LEVEL VALUES - HIGH EFFICIENCY PLUS
Standard D Models
Sound
Measurement Overall
dB(A)
Frequency (Hz) dB
63 125 250 500 1000 2000 4000
OPC500HE+D8
Power 100 76 89 92 102 93 85 74
Pressure @ 10m 68 44 57 60 70 61 53 42
OPC525HE+D10
Power 98 77 90 91 100 92 85 74
Pressure @ 10m 66 45 58 59 68 60 53 42
OPC550HE+D10
Power 96 77 90 90 96 91 85 74
Pressure @ 10m 64 45 58 58 64 59 53 42
OPC600HE+D10
Power 97 76 90 91 96 92 87 74
Pressure @ 10m 65 44 58 59 64 60 55 42
OPC650HE+D10
Power 98 76 90 92 97 93 88 74
Pressure @ 10m 66 44 58 60 65 61 56 42
OPC700HE+D12
Power 97 77 92 95 97 93 87 77
Pressure @ 10m 64 44 59 62 64 60 54 44
OPC750HE+D12
Power 97 77 93 97 96 93 85 79
Pressure @ 10m 64 44 60 64 63 60 52 46
OPC800HE+D14
Power 97 78 92 98 96 92 85 78
Pressure @ 10m 64 45 59 65 63 59 52 45
OPC850HE+D14
Power 97 77 92 99 96 90 84 77
Pressure @ 10m 64 44 59 66 63 57 51 44
OPC900HE+D16
Power 98 78 92 101 98 91 86 76
Pressure @ 10m 65 45 59 68 65 58 53 43
OPC950HE+D18
Power 100 79 93 102 100 92 87 76
Pressure @ 10m 67 46 60 69 67 59 54 43
OPC1000HE+D18
Power 99 79 93 102 99 93 87 77
Pressure @ 10m 66 46 60 69 66 60 54 44
OPC1100HE+D18
Power 99 79 93 101 98 94 87 78
Pressure @ 10m 66 46 60 68 65 61 54 45
Quiet DQ Models
Sound
Measurement Overall
dB(A)
Frequency (Hz) dB
63 125 250 500 1000 2000 4000
OPC500HE+DQ12
Power 94 82 80 89 94 89 81 70
Pressure @ 10m 61 49 47 56 61 56 48 37
OPC525HE+DQ12
Power 92 82 81 87 92 88 80 69
Pressure @ 10m 59 49 48 54 59 55 47 36
OPC550HE+DQ12
Power 90 82 81 85 88 87 80 68
Pressure @ 10m 57 49 48 52 55 54 47 35
OPC600HE+DQ12
Power 91 82 81 87 89 88 82 68
Pressure @ 10m 58 49 48 54 56 55 49 35
OPC650HE+DQ12
Power 92 82 80 88 90 89 84 69
Pressure @ 10m 59 49 47 55 57 56 51 36
OPC700HE+DQ14
Power 92 83 86 92 89 89 83 73
Pressure @ 10m 59 50 53 59 56 56 50 40
OPC750HE+DQ16
Power 92 84 88 94 89 89 80 75
Pressure @ 10m 59 51 55 61 56 56 47 42
OPC800HE+DQ16
Power 92 84 87 96 89 87 80 74
Pressure @ 10m 59 51 54 63 56 54 47 41
OPC850HE+DQ18
Power 91 84 84 96 89 85 80 72
Pressure @ 10m 58 51 51 63 56 52 47 39
OPC900HE+DQ20
Power 93 85 85 99 91 86 82 71
Pressure @ 10m 60 52 52 66 58 53 49 38
OPC950HE+DQ20
Power 95 85 85 100 92 87 83 69
Pressure @ 10m 62 52 52 67 59 54 50 36
OPC1000HE+DQ20
Power 94 85 86 99 91 89 83 72
Pressure @ 10m 61 52 53 66 58 56 50 39
OPC1100HE+DQ20
Power 94 85 86 99 91 90 83 73
Pressure @ 10m 61 52 53 66 58 57 50 40
1 dB(A) is the overall sound level, measured on the A scale.
2 All sound data measured at nominal conditions: Water in/out 12/7°C at 35°C ambient.
3 Based on standard unit, for units fitted with optional extras, please contact Airedale.
The Sound Pressure data quoted is only valid in free field conditions, where the unit is installed on a reflective base. If the equipment is
placed adjacent to a reflective wall, values may vary to those stated, typically increasing by 3dB for each side added.
