Alamo RHINO 1900 - Manual (Page 131)

OPERATION
1900 07/11 Operation Section 4-21
© 2011 Alamo Group Inc.
OPERA
T
ION
An angle float position can be selected which allows the flail head to automatically angle itself to follow the
contours of the ground. To obtain this position the control lever must be pushed away from the operator beyond
its normal range until it locks into the float position. To return to normal operation the float position must be
manually deselected. When working with head angle float the flail head must be in balance about its mounting
point. Failure to observe this will result in a poor cut.
