ASSEMBLY
1900 07/11
Assembly Section 3-8
© 2011 Alamo Group Inc.
ASSEMBL
Y
•
Adjust using the mounting hole that allows the
P.T.O. and gearbox shaft to align as near as
possible.
•
Fit positioning stops - these remain in position
until tractor is changed.
•
Lower tractor linkage control so that the
machine weight is taken by the yoke.
