Algo-3226-CM
4. Equipment and Software Validated
The following equipment and software were used for the sample configuration provided:
Hardware Component Version
Avaya S8800 Server and G450 Media
Gateway Avaya Aura® Communication Manager 6.0.1
SP 3 (R016x.00.1.510.1 w/Patch 19009)
Avaya 9600 Series IP Telephones 3.1 (H.323)
2.6.4 (SIP)
Algo 3226 Trunk Port FXO Doorphone 1.04
5. Configure Avaya Aura® Communication Manager
This section describes the steps for configuring a loop start trunk for the 3226 Trunk Port FXO
Doorphone. In addition, routing to the doorphone is also covered. Use the System Access
Terminal (SAT) to configure Communication Manager and log in with the appropriate
credentials.
5.1. Configure Loop Start Trunk
Configure the Trunk Group form as shown below. This trunk group is used for calls to the
3226 Doorphone. Set the Group Type field to co, set the Trunk Type field to loop-start, and
specify the extension to dial when the call button on the doorphone is pressed. This extension is
specified in the Incoming Destination field (e.g., 77301). Configure the other fields in bold and
accept the default values for the remaining fields.
add trunk-group 100 Page 1 of 22
TRUNK GROUP
Group Number: 100 Group Type: co CDR Reports: y
Group Name: Algo 3226 Doorphone COR: 1 TN: 1 TAC: 1100
Direction: two-way Outgoing Display? n
Dial Access? n Busy Threshold: 255 Night Service:
Queue Length: 0 Country: 1 Incoming Destination: 77301
Comm Type: voice Auth Code? n Digit Absorption List:
Prefix-1? y Trunk Flash? n Toll Restricted? y
Trunk Type: loop-start
On Page 6 of the trunk group form, specify an available analog port.
add trunk-group 100 Page 6 of 22
TRUNK GROUP
Administered Members (min/max): 1/1
GROUP MEMBER ASSIGNMENTS Total Administered Members: 1
Port Code Sfx Name Night Mode Type Ans Delay
1: 001V208
2:
