9
Technical data
INPUTS
PROCESS VALUE INPUT INP1
Resolution:
> 14 bits
Decimal point:
0 to 3 digits behind the decimal point
Dig. input filter:
adjustable 0,000...9999 s
Scanning cycle:
100 ms
Measured value
correction:
2-point or offset correction
Thermocouples
r
Table 1 (page 27 )
Input resistance:
³ 1 MW
Effect of source resistance:
1
mV/W
Cold-junction compensation
Maximal additional error:
± 0,5 K
Sensor break monitoring
Sensor current:
£1 mA
Configurable output action
Resistance thermometer
r
Table 2 (page 27 )
Connection:
2 or 3-wire
Lead resistance:
max. 30 Ohm
Input circuit monitor:
break and short circuit
Special measuring range
BlueControl (engineering tool) can be used to
match the input to sensor KTY 11-6
(characteristic is stored in the controller).
Physical measuring range:
0...4500 Ohm
Linearization segments
16
Current and voltage signals
r
Table 3 (page 27 )
Span start, end of span: anywhere within measuring range
Scaling:
selectable -1999...9999
Linearization:
16 segments, adaptable with
BlueControl
Decimal point:
adjustable
Input circuit monitor:
12,5% below span start (2mA, 1V)
CONTROL INPUT DI1
Configurable as switch or push-button!
Connection of a potential-free contact suitable
for switching “dry” circuits.
Switched voltage:
2,5 V
Current:
50
mA
GALVANIC ISOLATION
Safety isolation
Function isolation
OUTPUTS
OUTPUT OUT LC
Function:
Interruption of the power supply if the set limit
is exceeded or fallen short.
Contact type:
potential-free changeover contact
Max.contact rating:
500 VA, 250 V, 2A at 48...62 Hz,
resistive load
Min. contact rating:
5V, 10 mA AC/DC
Operating life (electr.):
600.000 duty cycles with max.
contact rating
OUTPUTS OUT1, OUT2
Function:
Additional alarms with MAX, MIN or MAX+MIN
monitoring with adjustable hysteresis.
Monitored signals:
w
process value (absolut)
w
difference to the limit (relative)
w
sensor break / short circuit
According to the input type, the input signal is
monitored to sensor break, polarity error and
short circuit
Contact type:
2 NO contacts with common
connection
Max. contact rating:
500 VA, 250 V, 2A at 48...62 Hz,
resistive load
Min. contact rating:
6V, 1 mA DC
Operating life (electr.): 800.000 duty cycles with max. rating
Note:
If the relays OUT1...OUT LC operate external
contactors, these must be fitted with RC
snubber circuits to manufacturer specifications
to prevent excessive switch-off voltage peaks.
POWER SUPPLY
Dependent of order
Technical data
TB40-1
25
Power supply connections Process value input INP1
Digital input di1
Relay outputs OUT 1,2
Relay output OUTLC
