4.2 Configuration
Lim
Name Value range Description Default
Fcn.1
Function of limit 1 3
3 Measured value monitoring + latching of the alarm status of
the upper limit. A latched alarm can be reset by the error
list, the digital input or the RESET-key (-> LOGI/
Err.r).
TW_S
1
4 Measured value monitoring + latching of the alarm status of
the lower limit. A latched alarm can be reset by the error
list, the digital input or the RESET-key (-> LOGI/
Err.r).
TW_S
1
5 Measured value monitoring upper limit (no latching) TW
1
6 Measured value monitoring lower limit (no latching) TW
1
Fcn.2 / 3 Function of limit 2 / 3 0 / 0
0 switched off
1 measured value monitoring
2 Measured value monitoring + latching of the alarm status.
A latched alarm can be reset by the error list, the digital
input DI1 or the RESET-key (-> LOGI/ Err.r).
Src.2 / 3 Source of limit 2 / 3 0 / 0
0 process value
1 control deviation xw (process value - set-point)
Hour OFF...10000 Operating hours (only visible with BlueControl!) OFF
Swit OFF...10000 Output switching cycles (only visible with BlueControl!) OFF
1
TW: Temperature monitor
TW_S: Temperature monitor with stored alarm
InP.1
Name Value range Description Default
S.tYP
Sensor type selection 1
0 thermocouple type L (-100...900°C), Fe-CuNi (DIN)
1 thermocouple type J (-100...1200°C), Fe-CuNi
2 thermocouple type K (-100...1350°C), NiCr-Ni
3 thermocouple type N (-100...1300°C), Nicrosil-Nisil
4 thermocouple type S (0...1760°C), PtRh-Pt10%
5 thermocouple type R (0...1760°C), PtRh-Pt13%
6 thermocouple type T (-200...400°C), Cu-CuNi
7 thermocouple type C (0...2315°C), W5%Re-W26%Re
8 thermocouple type D (0...2315°C), W3%Re-W25%Re
9 thermocouple type E (-100...1000°C), NiCr-CuNi
10 thermocouple type B (0/100...1820°C), PtRh-Pt6%
18 special thermocouple
Configuration level
Configuration 14 TB40-1
