21
8. Put the hybridisers in the position you want to use them.
9. Position the wall plate and mark the position of the holes.
10. Use the appropriate screws and fixings to attach the wall plate to the wall; ensure that the screws
are tight.
Hybrigene with wall bracket attached
11. Re-position the hybridisers placing the wall bracket over the wall plate.
12. Use the thumb-screw to attach the wall bracket to the wall plate.
Fixing Procedure for three Hybrigenes
If you have three units, repeat the above process attaching a stacking plate between each pair of
units.
OPERATION
SWITCHING ON
Once your Hybrigene is connected to a power supply, switch it on using the power switch next to the
power inlet socket on the rear panel.
THE FRONT PANEL CONTROLS
The front panel controls consist of a speed control knob for adjusting the tube rotation speed and a
temperature controller.
The front panel controls
Wall fixings
Wall bracket
Wall plate
