P A G E 18
M i c r o C a r r i e r S t i r r e r O P E R A T O R ’ S M A N U A L
INSTALLATION
Connections
• Before connecting to the main power supply CHECK that the
CORRECT VOLTAGE has been SELECTED on the switch
beside the mains socket.
• Connect the mains cable to a suitable supply according to the
table below. Note that the unit must be earthed to ensure
proper electrical safety.
CONNECTIONS 230V 110/120V
Live Brown Black
Neutral Blue White
Earth Green/yellow Green
• The fused plug supplied with the mains lead for use in the UK is
fitted with the following value fuse to protect the cable. The fuse
in the unit protects the unit and the operator.
All units 230V 5 Amp
Magnet Adjustment
• Each of the MCS platforms may be used with two or more sizes
of culture vessel, except the MCS-104XL which is set for 5 litre
vessels only.
• The position of the units magnet(s) must be adjusted for the
particular vessel being used to give the optimum stirring action.
• MCS-102L, MCS-104L and MCS-104S units have their magnets
set for 500 ml vessels when they leave Techne.
• MCS-101L units have their magnets set for 5 litre vessels when
they leave Techne.
• Remove screws from the sides of the unit. Unscrew the location
bosses.
• Remove the cover and position the magnets as follows:
