P A G E 17
M i c r o C a r r i e r S t i r r e r O P E R A T O R ’ S M A N U A L
Dimensions
Stirrer Units MCS-101L MCS-102L MCS-104S MCS-104L MCS-104XL
Width mm 395 140 250 395 530
Depth mm 495 400 365 495 595
Height mm 90 90 90 90 90
Net Weight 6.5Kg 3.0Kg 4.1Kg 6.1Kg 11.4Kg
(excl vessel)
Vessels
per system
1 2 4 4 4
Max
Vessel Size 5 litre
1 litre 500 ml 5 litre 5 litre
Culture Vessels 125 ml 250 ml 500 ml 1 litre 3 litre 5 litre
Gross Volume 250 ml 500 ml 1 litre 2 litre 6 litre 10 litre
Nom Working Vol 125 ml 250 ml 500 ml 1 litre 3 litre 5 litre
Working Vol 50 to 100 to 200 to 500 to 1.5 to 2 to
Range 175 ml 350 ml 700 ml 1500 ml 3.5 litre 7 litre
Height 145 mm 170 mm 205 mm 263 mm 284 mm 365 mm
Diameter 65 mm 80 mm 100 mm 140 mm 215 mm 240 mm
Top Thread Size 42 mm 42 mm 42 mm 42 mm 60 mm 60 mm
Side Thread Size 20 mm 20 mm 30 mm 42 mm 42 mm 24 mm
Side port size 14 mm 14 mm 23 mm 33 mm 33 mm 18 mm
No of side necks 2 2 2 2 2 5
Sterilisation of Glassware
In the interests of public health and the safety of our employees we
cannot accept any returned glassware without our previous
authorisation.
We require a certificate of sterilisation from the user before giving
such authorisation.
A suitable form of certificate is enclosed with the glassware when it
is despatched from Techne.
