Commands/R Commands/R Commands/R Commands/R Commands/Responses esponses esponses esponses esponses
The FGV series of force gauges has the ability to recog-
nize and respond to various commands from outside
peripherals. If for instance the gauge receives a legitimate
command from a PC, it will respond by sending back the
same code indicating to the PC that the command was
recognized. If for example the command is a request for
average data output, it will send the data and the code NA
etc. If the gauge recognizes an error while it is receiving a
command, an error symbol is transmitted back to the PC
indicating the exact nature of the error.
Commands to FGV Gauge
AAcr: Tare
ABcr: Stop output
ACcr: Change to peak mode
ADcr: Change to average mode
AEcr: Peak reset
AFcr: Change units to kg (g)
AGcr: Change units to N
AHcr: Change units to lb (oz)
BAcr: Data output request
BBcr: Continuous data output request
(10 times/sec)
BCcr: Model name confirmation request
BDcr: Units confirmation request
BEcr: Peak data output request
Response from FGV Gauge
NA!!!!!!cr: Average data output
NB!!!!!!cr: Peak data output
4-digit number with decimal point
sign (+ or –)
NE!!cr: Model number
Specifications Specifications Specifications Specifications Specifications
02 03 04 05 06 07 08 09
FGV-0.5 FGV-1 FGV-2 FGV-5 FGV-10 FGV-20 FGV-50 FGV-100
0 1 2
N Kg (g) lb (oz)
NH!cr: Unit
Error symbols:
OBcr: Command error
ODcr: Overload error
OEcr: Parity error
SHIMPO INSTRUMENTS 1701 Glenlake Avenue Itasca, IL 60143 (630) 924-7138 Fax (630) 924-0342
MODELS MODELS MODELS MODELS MODELS FGV FGV FGV FGV FGV-200H -200H -200H -200H -200H FGV FGV FGV FGV FGV-300H -300H -300H -300H -300H FGV FGV FGV FGV FGV-500H -500H -500H -500H -500H
200.0 lb. 300.0 lb 500.0 lb
CAP CAP CAP CAP CAPACITY ACITY ACITY ACITY ACITY 100.0 kg 150.0 kg 250.0 kg
1000 N 1500 N 2500 N
RESOL RESOL RESOL RESOL RESOLUTION UTION UTION UTION UTION 0.1 lb 0.1 lb 0.1 lb
0.1 kg 0.1 kg 0.1 kg
1 N 1 N 1 N
ACCURACY ACCURACY ACCURACY ACCURACY ACCURACY ±0.2% FS plus 1/2 digit at 73°F (23°C)
DISPL DISPL DISPL DISPL DISPLAAAAAYYYYY 4-Digit LCD 12mm high.
Reversible by pressing switches.
Minus sign for tension.
AVERAGE/PEAK MODE AVERAGE/PEAK MODE AVERAGE/PEAK MODE AVERAGE/PEAK MODE AVERAGE/PEAK MODE Yes (Selectable)
LLLLLOW BA
OW BA OW BA OW BA OW BATTTTTTERY TERY TERY TERY TERY Yes
INDICA INDICA INDICA INDICA INDICATION TION TION TION TION
DISPL DISPL DISPL DISPL DISPLAAAAAY UPDA Y UPDA Y UPDA Y UPDA Y UPDATE TE TE TE TE 0.3 second
SAMPLING R SAMPLING R SAMPLING R SAMPLING R SAMPLING RAAAAATE TE TE TE TE 35 times per second
OVERL OVERL OVERL OVERL OVERLOAD OAD OAD OAD OAD 200% of FS 150% of FS
POWER POWER POWER POWER POWER Rechargeable Ni-Cad batteries
or AC adapter/charger
AUTO POWER OFF AUTO POWER OFF AUTO POWER OFF AUTO POWER OFF AUTO POWER OFF 10 minutes
(not active if AC adapter/charger is in use)
BA BA BA BA BATTTTTTERY CHARGE TERY CHARGE TERY CHARGE TERY CHARGE TERY CHARGE 20 hours when battery is fully charged
RECHARGE RECHARGE RECHARGE RECHARGE RECHARGE 12 hour approx. (over charge protection)
TEMPER TEMPER TEMPER TEMPER TEMPERAAAAATURE TURE TURE TURE TURE 32° - 104°F (0° - 40°C)
DIMENSIONS DIMENSIONS DIMENSIONS DIMENSIONS DIMENSIONS 8.5"L x 3.4"W x 2.2D (214 x 82 x 55mm)
WEIGHT WEIGHT WEIGHT WEIGHT WEIGHT 2 lb (900g)
OVERL OVERL OVERL OVERL OVERLOAD OUTPUT OAD OUTPUT OAD OUTPUT OAD OUTPUT OAD OUTPUT One NPN OC transistor for tension,
one NPN OC transistor for compression
ACCESSORIES ACCESSORIES ACCESSORIES ACCESSORIES ACCESSORIES AC adapter/charger, carrying case, hook,
(INCL (INCL (INCL (INCL (INCLUDED) UDED) UDED) UDED) UDED) chisel, flat head, notched head, cone head,
extension rod, hanger and handles
and analog output cable.
ACCESSORIES ACCESSORIES ACCESSORIES ACCESSORIES ACCESSORIES Test stands, RS232C cable,
(AVAILABLE) (AVAILABLE) (AVAILABLE) (AVAILABLE) (AVAILABLE) overload output cable
All dimensions in mm
Dimensions Dimensions Dimensions Dimensions Dimensions
OFcr: Format error
OGcr: Summing error
OHcr: Overrun error
