SHIMPO DT-209X-S12 User Manual
Page 5
1
Model DT-209X casing is similar to standard DT-207/DT-205L with addition of
USB port, analog output, and selector switch.
DT-209X Parts Description
9. Power Switch
3. Measurement Mode Selector
6. Laser Beam Opening
1. USB Connector
7. Display
5. Contact Adapter
(DT-ADP-200L)
4. Contact
2. Analog Output
8. Unit Selector Switch
10. Memory Button
