REVO America www.revoamerica.com RESPTZ37-SERIES
19
IN:
Input. Specifies the type of input that will trigger the alarm.
NO:
Normally open.
NC:
Normally closed.
OFF:
Ignore input.
OUT:
Output (OUT1 thru OUT4). Specifies the alarm output from the camera.
ON:
TTL output on.
OFF:
No output
HLD:
Hold. Alarm will be held for programmed time (03 to 99 seconds).
LATCH: ON:
Alarm message will remain on the screen even though alarm input
is deactivated.
OFF
: Alarm message will disappear on the screen after programmed
hold time when alarm input is deactivated.
DWELL:
Dwell time between multiple alarms (03 to 99 seconds).
RELAY OUT SETUP:
The RELAY OUT SETUP is useful when the outdoor housing is used
with the dome. For example: when you connect the relay output of the
dome to the heater connector of the outdoor housing, the relay output
will operate during the setting time only.
RELAY OUT SETUP
OUT1 : ALARM
OUT2 : 1 MIN
OUT3 : ALARM
OUT4 : 5 MIN
EXIT(ESC TO EXIT)
OUT1/OUT3: ALARM:
Alarm output is triggered by an alarm input or by the ALARM
shortcut key on the keyboard.
OUT2/OUT4: 1-5 MIN (minute):
Alarm output is active during this configured time only
by the Function run option in the DOME MENU or the shortcut key on
the keyboard.
Note that this 1-5 MIN setting is not operated by an alarm.
