RESPTZ37-SERIES
17
1. Press the MENU key to display the main menu on the monitor. Scroll to Tour and move the
joystick to the right to enter the Tour menu. Or, just press the TOUR key on the keyboard.
2. Select NUMBER and set the desired Tour number by pushing the joystick to the left or
right.
3. Choose a blank position to be programmed by moving the joystick up, down, right, or left.
4. To add a stored Preset, twist the joystick then the stored Preset number displays.
5. To use other functions in the Tour, press the TOUR, PTRN, or SCAN keys for Tour,
Pattern or Auto Scan respectively.
6. You can also overwrite the programmed number and to remove a stored number from the
Tour. Press the HOME key on the stored number, a blank position mark (---) will be
displayed.
7. Repeat steps 2 through 5 for each desired position. Each title will be displayed on top of the
line.
8. To create a unique title, refer to the Titling procedure.
9. Select SAVE AND EXIT and move the joystick to the right. Press the ESC key
to exit the
program without saving.
10. To store the Tour that you created as the default programmed action for the camera,
navigate to the DOME SETUP menu and select HOME FUNCTION. Refer to the Home
Function
procedure.
You can expand the Tour sequence by calling other programmed Tours.
NOTE
Speed only applies to Vector scans.
In the Tour mode, in conjunction with Preset and Auto Scan, you can make the camera travel from
a Preset position to another Preset position at a specific speed.
Example
: Preset 001>002>003>004>005>006, Auto Scan 01 starts at Preset 002, ends at Preset
003, Auto Scan 02 starts at Preset 005, ends at Preset 006; Tour 001, 002, A01, 004,
A02.
1 2 2-3 4 5~6, repeat
where : Quick move, - : Programmed speed
To change the Dwell time of the Preset in the Tour Setup menu:
1. Use the joystick to move the cursor to a stored Preset position.
