BIOS
- 32 -
Onboard Serial/Parallel Port
It allows you to select the onboard serial and parallel ports with their
addresses.
Setting: Serial Port 1 3F8/IRQ4 (Default)
Serial Port 2 2F8/IRQ3 (Default)
Parallel Port 378/IRQ7 (Default)
UART Mode Select
It determines the UART 2 mode in your computer.
Setting: IrDA/ASKIR/Normal (Default).
RxD, TxD Active
Setting: Hi, Hi/Hi, Lo (Default)/Lo, Hi /Lo, Lo.
IR Transmission Delay
Setting: Disabled/Enabled (Default).
UR2 Duplex Mode
Setting: Full/Half (Default).
Use IR Pins
Setting: RxD2,TxD2 / IR-Rx2Tx2 (Default).
Parallel Port Mode
Setting: SPP (Default) /EPP /ECP /ECP+EPP /Normal
EPP Mode Select
Setting: EPP1.9/EPP1.7 (Default)
ECP Mode Use DMA
Setting: 1/3 (Default).
BIOS
- 33 -
Serial Port 3 Use IRQ
Setting: IRQ10 (Default)/IRQ11.
Serial Port 4 Use IRQ
Setting: IRQ10 /IRQ11 (Default).
IT8888 ISA Decode IO >>>
It allows you to use the IT8888 ISA Decode IO menu to set the IO memory
range for the onboard ISA.
Decode I/O Space 0/ 1/ 2/ 3/ 4/ 5
It allows you to allocate system resources to the ISA bridge and to enable
.
.
the function correctly
Setting: Disabled, Enabled (Default)
Decode I/O Speed 0/ 1/ 2/ 3/ 4/ 5
It allows you to specify the speed of the ISA bus.
Setting: Subtractive Speed, Slow Speed, Medium Speed, Fast Speed.
Decode I/O Address 0/ 1/ 2/ 3/ 4/ 5 [15:4]
It allows you to allocate an address to the ISA bus. The address may range
from 0001 to 0FFF.
