-bit General Purpose I/O (DIO)
Connector: DIO
Type: One onboard 2x10pin Header
2.3.8 16
Installation
- 20 -
Pin Description
1 DO0
3 DO2
5 DO4
7 DO6
9 GND
11 DI0
13 DI2
15 DI4
17 DI6
19 +5V Pin Description
2 DO1
4 DO3
6 DO5
8 DO7
10 GND
12 DI1
14 DI3
16 DI5
18 DI7
20 +12V
Pin Description
1 RESET +
3 Power LED+
5 HD LED+
7 Speak+
9 PSON+ Pin Description
2 RESET -
4 Power LED-
6 HD LED-
8 Speak-
10 PSON-
2.4 Switches and Indicators
Connector: JFRT1
Type: One onboard 2x5pin Header
2.3.7 Audio Interface Port
Connector: AUDIO1
Type: One onboard 2x5pin Box Header
Pin Description
1 LINEL
3 MIC
5 GND
7 AGND
9 LOUT-L Pin Description
2 LINER
4 GND
6 NC
8 AGND
10 LOUT-R
AUDIO1
DIO
JFRT1
Output Port I/O Based Address : 208hex~20Fh; Pin1~Pin8 Input Port
I/O Based Address : 200hex~207h; Pin11~Pin18
Installation
- 21 -
2.5 CFD1: Compact Flash II Socket
Connector: CFD1
Pin Description
1 GND
3 DATA4
5 DATA6
7 CS#1
9 GND
11 GND
13 +5V
15 GND
17 GND
19 ADDR1
21 DATA0
23 DATA2
25 GND
27 DATA11
29 DATA13
31 DATA15
33 GND
35 IO WRITE
37 IRQ15
39 CSEL
41 IDE RESET
43 NC
45 DASP
47 DATA8
49 DATA10 Pin Description
2 DATA3
4 DATA5
6 DATA7
8 GND
10 GND
12 GND
14 GND
16 GND
18 ADDR2
20 ADDR0
22 DATA1
24 NC
26 GND
28 DATA12
30 DATA14
32 CS#3
34 IO READ
36 +5V
38 +5V
40 NC
42 IO READY
44 +5V
46 DIAG
48 DATA9
50 GND
Note:
1.After hot-swapping CF II, you must restart your system for device detecting
2.CF II and ATA channel are alternative
3.CF II Socket supports up to 4GB
