BIOS
- 28 -
CAS Latency
It allows CAS latency time in HCLKs. The system board designer should set
the values in this field, depending on the DRAM installed. Do not change the
values in this field unless you change specifications of the installed DRAM or
CPU. Setting: Auto (Default)/1.5/2.0/2.5/3.0/3.5.
Interleave Select
It allows you to Use the Interleave Select option to specify how the cache
memory is interleaved.
Setting: LOI (Default)/HOI.
XOR BA0
Setting: Disabled (Default)/Enabled.
XOR BA1
Setting: Disabled (Default)/Enabled.
XOR MB0
Setting: Disabled (Default)/Enabled.
3.5 Advanced Chipset Features
BIOS
- 29 -
XOR Bit Select
Setting: 18(Default)/19/20/21.
Video Memory Size
In order to determine how much memory is allocated to the video graphics
device.
Setting: None/8M(Default)/16M/32M/64M/128M/254M.
Output display
In order to specify the display devices the system is connected to.
Setting: Flat Panel/CRT (Default)/Panel & CRT.
Flat Panel Configuration
It allows you to open the Flat Panel Configuration menu.
Memory Hole At 15M-16M
In order to improve performance, certain space in memory can be reserve
for ISA cards. This memory must be mapped into the memory space belo
16 MB
Setting: Disabled (Default)/Enabled d
