2.2.1 Ethernet Connector
Connector: LAN1
Type: One external RJ-45 on bracket
Pin
1
3
5
7 Description
Tx
+
Rx +
NC
NC
Pin
2
4
6
8 Description
Tx-
NC
Rx-
NC
2.2.2 Power Connector
ATX Feature Connector: ATX1
Type: Onboard 1x3pin Wafer Header
Pin Description
1 #PS-ON
2 GND
3 5VSB
ATX Power Connector: PWR1
Type: Onboard 1x4pin Header
Pin Description
1 +5V
2 GND
3 GND
4 +12V
LAN1
PWR1
ATX1
Installation Installation
- 12 - - 13 -
2.2 Connectors Quick Reference
Label
ATX1
AUDIO1
CFD1
COM1
COM2
GPIO
FDD1
IDE1
INV1
JFRT1
KBM1(PS/2)
LAN1
LCD1
LVDS1
LPT1
PC104
PWR1
SW1
USB1
USB2
VGA1 Function
ATX Feature Connector
Audio Interface Connector
Compact Flash Disk
Serial Port: COM1
Serial Port: COM2
16-bit GPIO
Share with LPT Connector
Enhanced IDE Connector
LCD Inverter Connector
Front Panel Connector
PS/2 Keyboard & Mouse Connector
10/100M LAN1Connector
LCD Connector for TTL
LCD Connector for LVDS
Parallel Port
ISA PC-104 Interface
Power Connector
Reset Connector
USB Port 1,2
USB Port 3,4
CRT SVGA Connector
Connectors
