2 wire comp.
• V2H7 Entry of leadwire compensation on RTD 2 wire connection
Entry: (0.00 to 30.00) Ohm
0.00 Ohm
Failsafe mode
• V2H8
Entry of failure signal on sensor fracture or short circuit.
Entry:
Max (
≥ 21.0 mA)
Min (
≤ 3.6 mA)
Min
Function group: USER LINERIZATION
The following function fields are only active in the unit function SENSORTYPE (V2H0) on selection of customer-specific linearization (Polynomial TC or RTD)
Coefficient X0
• V3H0
Input of first coefficient for customer-specific linearization (4th order polynomial with five
coefficients), see 6.8, Interactive setting up of the temperature transmitter
Coefficient X1
• V3H1
Input COEFFICIENT X1, see 6.8, Interactive setting up of the temperature transmitter
Coefficient X2
• V3H2
Input COEFFICIENT X2, see 6.8, Interactive setting up of the temperature transmitter
Coefficient X3
• V3H3
Input COEFFICIENT X3, see 6.8, Interactive setting up of the temperature transmitter
Coefficient X4
• V3H4
Input COEFFICIENT X4, see 6.8, Interactive setting up of the temperature transmitter
Function group: SERVICE
Error code
• V9H0
Display of actual error code.
Display: See “8.1, Application fault messages”
0
Last diagnostic
• V9H1
Display of previous error code.
Display: See “8.1, Application fault messages”
0
Config. changed
• V9H2
Parameter changes are done.
Display: Yes/no
No
Min Indication
• V9H3
Display the minimum process value. The process value is accepted at the beginning of the
measurement.
Hint! Min. process value will be changed to the actual process value on write. On reset to factory
default, the default value is entered.
+10 000
Max Indication
• V9H4
Display the maximum process value. The process value is accepted at the beginning of the
measurement.
Hint! Max. process value will be changed to the actual process value on write. On reset to factory
default, the default value is entered.
-10 000
