Function group: BASIC CALIBRATION
Type of sensor
• V2H0
Entry of sensor used:
Sensor type Range start Range end value
(-10 to 75) mV
-10 mV 75 mV
(10 to 400)
Ω
10
Ω
400
Ω
(10 to 2000)
Ω
10
Ω
2000
Ω
Pt100 DIN -200
°C [-328 °F]
850
°C [1562 °F]
Pt100 JIS -200
°C [-328 °F]
649
°C [482 °F]
Pt500 -200
°C [-328 °F]
250
°C [482 °F]
Pt1000 -200
°C [-328 °F]
250
°C [482 °F]
Ni100 -60
°C [-76 °F]
180
°C [356 °F]
Ni500 -60
°C [-76 °F]
150
°C [302 °F]
Ni1000 -60
°C [-76 °F]
150
°C [302 °F]
Polynom RTD -270
°C [-454 °F]
2500
°C [4532 °F]
Type B 0
°C
[32
°F]
1820
°C [3308 °F]
Type C 0
°C
[32
°F]
2320
°C [4208 °F]
Type D 0
°C
[32
°F]
2495
°C [4523 °F]
Type E -270
°C [-454 °F]
1000
°C [1832 °F]
Type J -210
°C [-346 °F]
1200
°C [2192 °F]
Type K -270
°C [-454 °F]
1372
°C [2501 °F]
Type L -200
°C [-328 °F]
900
°C [1652 °F]
Type N -270
°C [-454 °F]
1300
°C [2372 °F]
Type R -50
°C [-58 °F]
1768
°C [3214 °F]
Type S -50
°C [-58 °F]
1768
°C [3214 °F]
Type T -270
°C [-454 °F]
400
°C [752 °F]
Type U -200
°C [-328 °F]
600
°C [1112 °F]
Polynom TC -270
°C [-454 °F]
2500
°C [4532 °F]
Pt100 DIN
Temp. Compensation
• V2H1
Selection of temperature compensation of the cold junction when using customer specific
linearization of the TC polynomial
Input:
None, Type B, Type C, Type D, Type E, Type J, Type K, Type L, Type N, Type R, Type S, Type T,
Type U
None
Measuring Unit
• V2H2 Enter engineering units.
Entry:
°C, °F, K
°C
Current output
• V2H3
Enter standard (4 to 20) mA or inverse (20 to 4) mA current output signal.
Entry:
4-20 mA
20-4 mA
4-20 mA
Value of 4 mA
• V2H4
Entry: For limits see unit function SENSOR TYPE
0.00
°C
Value of 20 mA
• V2H5 Entry: For limits see unit function SENSOR TYPE.
100.00
°C
Connection
• V2H6
• RTD connection
Entry of RTD Connection mode
Entry:
2 wire
3 wire
4 wire
3 wire
