Model 4069E ExtrudeIR

TM

Instruction Manual

Dimensions and Specifications

Research, Inc.

Page 26 of 26


Accessories, Spare, and Replacement Parts – Heater

Model

Description


103390-003
103390-004
103390-005
103390-012
103390-007
103390-010



106721-001
106721-002
106721-003
106721-004



106778-001
106778-002



106895-001
106895-002
106895-003
106895-004

106895-005
106895-006
106895-007
106895-008

M4069C

Replacement Lamp For:

12kW or 18kW maximum-power rated heater (10 inch length, 1000-watts)
24kW or 36kW maximum-power rated heater (10 inch length, 2000-watts)
19kW or 29kW maximum-power rated heater (16 inch length, 1600-watts)
56KW maximum power rated heater (16 inch length, 3600-watts)
30kW or 45kW maximum-power rated heater (25 inch length, 2500-watts)
46kW or 68kW maximum-power rated heater (38 inch length, 3800-watts)

Replacement Reflector For:

10-inch length
16-inch length
25-inch length
38-inch length

Replacement End Reflectors (Four required per heater) for:

12-reflector size heater
18-reflector size heater

Spare Split Quartz Liner Half (Two required per heater) for:

12-reflector, 10-inch length
12-reflector, 16-inch length
12-reflector, 25-inch length
12-reflector, 38-inch length

18-reflector, 10-inch length
18-reflector, 16-inch length
18-reflector, 25-inch length
18-reflector, 38-inch length

Additional Operation Manual
