Model 4069E ExtrudeIR

TM

Instruction Manual

Dimensions and Specifications

Research, Inc.

Page 25 of 26

Accessories, Spare, and Replacement Parts – Controls

Model

Description




096191-006
107556-009
086445-016
090744-020
099395-001
099396-001
107549-001
099556-003
099556-010
080821-001
055899-015
107321-001
066798-004
055300-289



107525-001
107392-004
107392-001
107391-003
107390-002
107390-001
107393-003
107439-001


106783-011
106783-012
106783-013
106783-014

106784-011
106784-012
106784-013
106784-014

106783-013
106784-013


107358-011
107358-012
107358-014
107358-014

107396-011
107396-012
107396-013
107396-014




Control Cabinet:


Contactor- 3 phase, 100 amp, 24 VDC coil
Fuse-Cubefuse, 100 amp
Fuse-Time Delay, “CC”, 6 amp, 600 VAC
Fuse-Current Lim “CC” 1.6 amp
Switch-On /Off, 3 phase, 100 amp
Switch Actuator-Red/Yellow
Power Supply-480 VAC in, 24VDC out
PLC-115/240, 8 DC in, 6 relay out
Output Module-PLC Dl05/06 4 PT
Relay-DPDT, 10 amp, 24VDC, 650 ohm
Relay-SS, DC, 125 amp, 480 VAC
Transformer-250 VA, 480/240 to 240/120
Varistor-Assembled, 480 VAC
Resistor-MF,1/4W, 1%, 10K ohm


Control Console:
Watlow F4P Series process controller
Switch-Push Button, 2 head
Switch-Push Button, E-stop
Switch-Rotary, 3 position
Contact Block-Normally open
Contact Block-Normally closed
Indicator Light-Amber, 24-120 VAC/DC
Actuator-Telescopic, 8” lift, 24 V

Cart
Replacement Gas Spring for 4069-12R-10L
Replacement Gas Spring for 4069-12R-16L
Replacement Gas Spring for 4069-12R-25L
Replacement Gas Spring for 4069-12R-38L

Replacement Gas Spring for 4069-18R-10L
Replacement Gas Spring for 4069-18R-16L
Replacement Gas Spring for 4069-18R-25L
Replacement Gas Spring for 4069-18R-38L

Replacement Gas Spring for 4069-12-DUAL
Replacement Gas Spring for 4069-18-DUAL

Gas Spring with Latch Replacement
Replacement Gas Spring & Latch for 4069-12R-10L
Replacement Gas Spring & Latch for 4069-12R-16L
Replacement Gas Spring & Latch for 4069-12R-25L
Replacement Gas Spring & Latch for 4069-12R-38L

Replacement Gas Spring & Latch for 4069-18R-10L
Replacement Gas Spring & Latch for 4069-18R-16L
Replacement Gas Spring & Latch for 4069-18R-25L
Replacement Gas Spring & Latch for 4069-18R-38L
