Model 4069E ExtrudeIR

TM

Instruction Manual

Operating

Instructions

Research, Inc.

Page 7 of 26

DIMENSIONS



A

32.63

44.00

B

C

D DIA

MODEL NUMBER

A

B

MIN MAX

C

MIN MAX

D DIA

4069P-12R-10L

16.13
(410)

36.75 44.75

(933) (1137)

44.97 52.97

(1142) (1345)

3.22
(82)

4069P-12R-16L

21.75
(552)

36.75 44.75

(933) (1137)

44.97 52.97

(1142) (1345)

3.22
(82)

4069P-12R-25L

30.75
(781)

36.75 44.75

(933) (1137)

44.97 52.97

(1142) (1345)

3.22
(82)

4069P-12R-38L

43.75

(1111)

36.75 44.75

(933) (1137)

44.97 52.97

(1142) (1345)

3.22
(82)

4069P-18R-10L

16.13
(410)

38.00 46.00

(965) (1168)

47.89 55.89

(1216) (1419)

5.90

(150)

4069P-18R-16L

21.75
(552)

38.00 46.00

(965) (1168)

47.89 55.89

(1216) (1419)

5.90

(150)

4069P-18R-25L

30.75
(781)

38.00 46.00

(965) (1168)

47.89 55.89

(1216) (1419)

5.90

(150)

4069P-18R-38L

43.75

(1111)

38.00 46.00

(965) (1168)

47.89 55.89

(1216) (1419)

5.90

(150)

4069P-12R-10L-DUAL

38.39
(975)

36.75 44.75

(933) (1137)

44.97 52.97

(1142) (1345)

3.22
(82)

4069P-18R-10L-DUAL

38.39
(975)

38.00 46.00

(965) (1168)

47.89 55.89

(1216) (1419)

5.90

(150)

IN

(MM)
