1
TORK MODEL
ELC71 ONE CHANNEL
ELC72 TWO CHANNEL
ENERGY AND LIGHTING CONTROL
READ INSTRUCTIONS CAREFULLY BEFORE
ATTEMPTING TO INSTALL TIME SWITCH. SEE
WARNING ON FRONT PANEL – Failure to comply with
instructions could result in personal injury and/or property
damage .
INSTALLATION:
UNIT IS TO BE INSTALLED BY A LICENSED ELECTRICIAN
1 . Remove unit from enclosure by pushing the inside
tab (located near the outside hasp) to the right .
Swing unit to left and remove .
2 . Mount the enclosure at eye level using screws
or other suitable fastening device . Bring supply
and load wires in through bottom or side knockouts .
3 . Reinstall unit by reversing step #1 above and
connecting wires to units as per suggested
wiring diagrams at back of manual .
4 . Unit should be programmed with AC power . Do
not program under super cap back up power .
CAPABILITIES
- 7 day scheduling
- 128 set points
- Astronomic programming
- 4 Signal (duration) programs
- 4 Duty Cycle programs
- 26 Holidays
- 10 Block holidays
- 2 Inputs for switches or photo sensor
- Momentary output
