KROHNE ECOFLUX IFS 1000 EN - Manual (Page 2)

2
Contents
System description 2
Product liability and warranty 2
Standards and approvals 2
Items included with supply 3
1 Important information for installation: PLEASE NOTE 4-5
2 Suggestions for installation 5
3 Instrument nameplate 6
4 Flowmeter versions 6
5 Installation in the pipeline 7
6 Torques 8
7 Grounding 8-9
8 Replacement of separate primary head IFS 1000 F 10
9 Spares and order numbers 10
10 Technical data 11
11 Dimensions and weights 12-13
Notes 14
Printed form to accompany flowmeters returned to Krohne 15
System description
ECOFLUX electromagnetic flowmeters are precision measuring instruments designed for the
linear flow measurement of process liquids.
The process liquids must be electrically conductive:
≥
0 5
µ
S/cm
≥
20
µ
S/cm for demineralized cold water
The full-scale range Q
100%
can be set as a function of the meter size:
DN 10 - 150 / 3 /
8
” - 6” Q
100%
= 0.1 - 760 m 3 /hr = 0.4 - 3350 US Gal/min
This is equivalent to a flow velocity of 0.3 - 12 m/s, or 1 - 40 ft/s.
Product liability and warranty
ECOFLUX electromagnetic flowmeters are designed solely for measuring the volumetric flowrate
of electrically conductive, liquid process products.
Flowmeters with the ECOFLUX primary head are not certified for use in hazardous locations.
Other flowmeter series are available for such applications.
Responsibility as to suitability and intended use of these electromagnetic flowmeters rests solely
with the operator.
Improper installation and operation of the flowmeters (systems) may lead to loss of warranty.
In addition, the “General conditions of sale” forming the basis of the purchase contract are
applicable.
If ECOFLUX flowmeters need to be returned to Krohne, please note the information given on the
last-but-one page of this manual. Krohne regret that they cannot repair or check your flowmeter(s)
unless accompanied by the completed form sheet.
Standards and approvals
Please refer to the installation and operating instructions for the signal converter.
