KROHNE ECOFLUX IFS 1000 EN - Manual (Page 13)

13
Dimensions in mm (in)
c
a
e
d
DN 10 - 15 / 3 / 8 ” - 1 / 2 ”
Dimension ”a” with fitted grounding rings (standard)
c
a
d
e
b
c
d
a
e
b
98 (3.86”)
136 (5.35”)
160 (6.30”)
105 (4.13”) 165 (6.50”)
71 (2.80”)
78 (3.07”)
140 (5.51”)
206 (8.11”)
DN 25 - 40 / 1” - 1 1 /
2
”
98 (3.86”)
136 (5.35”)
160 (6.30”)
105 (4.13”)
71 (2.80”)
78 (3.07”)
140 (5.51”)
206 (8.11”)
165 (6.50”)
DN 50 - 150 / 2” - 6”
98 (3.86”)
136 (5.35”)
160 (6.30”)
105 (4.13”)
71 (2.80”)
78 (3.07”)
140 (5.51”)
206 (8.11”)
165 (6.50”)
b
