11 Dimensions and weights
PLEASE NOTE
The total dimension for the height is obtained from dimension b (see table) plus the height
of the terminal box or the signal converter, see drawings.
The total weight is made up of the weight of the signal converter (see table)
plus the weight of the terminal box or signal converter, see below.
Meter size
Dimensions in mm (in)
Approx. weight 1)
DN mm
(in)
a
b
1) c
d
e
in kg
(lb)
DN 10
3
/
8
68
(2.68)
137
(5.39)
52
(2.05)
67
(2.64)
47
(1.85)
1.7
(3.7)
DN 15
1
/
2
68
(2.68)
137
(5.39)
52
(2.05)
67
(2.64)
47
(1.85)
1.7
(3.7)
DN 25
1
54
(2.13)
147
(5.79)
52
(2.05)
62
(2.44)
66
(2.60)
1.7
(3.7)
DN 40
1
1
/
2
78
(3.07)
162
(6.38)
76
(2.99)
70
(2.76)
82
(3.23)
2.6
(5.7)
DN 50
2
100
(3.94)
151
(5.94)
98
(3.86)
50
(2.58)
101
(3.98)
4.2
(9.3)
DN 80
3
150
(5.91)
180
(7.09)
146
(5.75)
65
(3.15)
130
(5.12)
5.7
(12.6)
DN 100
4
200
(7.87)
207
(8.15)
196
(7.72)
78
(3.66)
156
(6.14)
10.5
(23.1)
DN 150
6
200
(7.87)
271
(10.67)
196
(7.72)
110
(4.90)
219
(8.62)
15.0
(33.1)
Necessary distance between flanges
DN 10 - 15 /
3
/
8
” -
1
/
2
”
(flowmeter supplied with grounding rings)
Dimension a + 2
x
gasket thickness (2)
DN 25 - 150 / 1” - 6”
without grounding rings:
Dimension a only (no gaskets required)
with grounding rings:
Dimension a + 2
x
gasket thickness (2)
+ 2
x
3 mm or 2
x
0.12” (thickness of grounding rings)
1) Overall height ”b” and approx. weight without mounted terminal box or signal converter
2) Teflon-type gaskets to DIN 2690/ANSI B 16.21, deformable under pressure 8 - 16 N/mm
2
/1160 - 2320 psi,
to be provided by customer.
Terminal box
IFC 010 K signal converter
IFC 090 K signal converter
Weight approx.
0.5 kg (1.1 lb)
Weight approx.
1.6 kg (3.6 lb)
Weight approx.
2.3 kg (5.1 lb)
